Marin Lombard 1 700C grey matt/black gravel bike (A-2542E-E1-58)

Frame

Frame Series 2 Lombard, 6061 Aluminum, 700C Wheels, Relieved Head Tube and BB, Internal Cable Routing

Frame material Aluminium

Components

Steering wheel Marin Butted Alloy, Compact 16º Flared Drop

Handlebar support Marin 3D Forged Alloy

Grips Marin Microfiber Tape

Depreciation No

Rudders FSA No.8B

Fork 6061 Aluminum, Straight-Blade, Post-Mount Disc

Saddle Marin Beyond Road Concept

Bar Marin Alloy, 27.2mm

Drive

Type of derailleur Mechanical

Derailleurs 2x9

Number of gears 18

Front derailleur (model) Shimano Sora

Rear derailleur (model) Shimano Sora 9-Speed

Handles Shimano Sora 2x9-Speed

Crank mechanism Marin 3D Forged Alloy, 48/32T Chainrings, Ring Guard

Cassette / Freewheel Shimano HG-200, 11-34T

Chain KMC X9

Brakes

Brakes (model) Tektro Road Mechanical Disc, 160mm Rotor

Brake type Mechanical discs

Wheels

Wheel size 28"

Wheels Marin Aluminum Double Wall, 21mm Inner

Tyres Vee Tire, G-Sport, 700Cx40mm, Puncture Protection

Hubs Forged Aluminum Alloy, Disc, 32H

spokes 14g Black Stainless Steel

Additional information

Pedals included Yes

Folding condition of the bike Bike adjusted and pre-assembled

Other data

Sport Bicycles

Brand Marin

Leading colour Grey

Season Year-round

Model/product code Lombard 1 700C A-2542E-E1-58

Gender Male, Woman

Country of origin of the brand USA

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.

Model colour 2000091681

Below you will find information that will help you choose the right size when buying a Lombard 1 bike from Marin.

Size	S	M	L	XL
Height (cm)	160-168	168-175	175-183	183-188
A - STACK	546,8	561	580	594,2
B - REACH	393,2	399	404	409
	71,5	71,5	71,5	71,5
D - Steering tube (mm)	127	142	162	177
E - Kąt siodełka (°)	74	74	74	73,5
	520	540	560	580
	550	560	570	585
	280	280	280	280
	70	70	70	70
	430	430	430	430
	1030	1040	1051	1066
	774,37	792,33	811,78	829,8
	50	50	50	50

Advantages

Aluminium frame

This bike model has been made with the right materials to ensure maximum comfort. Durable aluminium was used for the frame, which stands out for its lightness. In addition, this material is characterised by a high strength index and resistance to bending.

28" wheels

The 28-inch wheels are characterised by prolonged wear and allow faster speeds, which are far easier to maintain. Compared to smaller sizes, these wheels provide better stability at higher speeds.

Mechanical disc brakes

This model of bike uses mechanical disc brakes, which have a low failure rate and high braking power. This type, thanks to its simple design, guarantees ease of eventual servicing.
