Frame
Frame Orbea Monocoque Race Carbon. Advanced Dynamics 167mm suspension technology. Concentric Boost 12x148 rear axle
Frame material Carbon fibre
Components
Steering wheel OC Mountain Control MC30, Rise20, Width 800
Handlebar support Alloy 3D forged, 35mm interface, -7º
Grips OC Lock On
Depreciation Full
Rudders Acros Alloy 1-1/8 - 1-1/2" Integrated
Fork Fox 38 Float Performance 170 Grip 3-Position QR15x110
Damper Fox FLOAT X Performance 2-Position Evol LV custom tune 230x62.5mm
Saddle ERGON SM Enduro
Bar OC Mountain Control MC21, 31.6mm, Dropper
Drive
Derailleurs 1x12
Number of gears 12
Rear derailleur (model) Shimano SLX M7100 SGS Shadow Plus
Handles Shimano SLX M7100 I-Spec EV
Crank mechanism Race Face Aeffect 32t
Cassette / Freewheel Shimano CS-M7100 10-51t 12-Speed
Chain Shimano M6100
Brakes
Brakes (model) Shimano M6120 Hydraulic Disc
Brake type Hydraulic discs
Wheels
Wheel size 29"
Wheels Race Face AR 30c Tubeless Ready
Tyres Maxxis Assegai 2.50" WT FB 120 TPI 3C Maxx Terra EXO+ TR, Maxxis Minion DHR II 2.40" WT FB 120 TPI 3C Maxx Terra Exo+ TR
Additional information
Folding condition of the bike Bike adjusted and pre-assembled
Other data
Sport Bicycles
Brand Orbea
Leading colour Green
Season Year-round
Model/product code Rallon M20 R27103PB
Gender Male, Woman
Country of origin of the brand Spain
Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.
Code 2000103877
Below you will find information that will help you choose the right size when buying a Rallon M20 bike from Orbea.
| Size | M | XL |
| Height (cm) | 160-180 | 180-200 |
| A - Seat tube (mm) | 415 | 460 |
| B - Horizontal pipe (mm) | 600 | 655 |
| C - Steerer tube (mm) | 100 | 120 |
| D - Rear triangle (mm) | 438 | 438 |
| E - Support height (mm) | 343 | 343 |
| F - Support lowering (mm) | 35 | 35 |
| G - Wheelbase (mm) | 1230 | 1289 |
| H - Head angle | 64/63,5 | 64/63,5 |
| I - Seat tube angle (°) | 77 | 77 |
| J - Crossover (mm) | 744 | 781 |
| K - Reach (mm) | 455 | 505 |
| L - Stack (mm) | 632 | 650 |
| M - Fork (mm) | 587,7 | 587,7 |
Advantages
Carbon frame
When designing this bike, the focus was on selecting the right materials to ensure the highest quality. Therefore, the frame is made of carbon, which combines lightness and resilience in addition to effectively damping vibrations.
Hydraulic disc brakes
This mountain bike model uses hydraulic disc brakes, which have a very low failure rate, so they will be trouble-free even during frequent use. The undoubted advantage is greater braking power and modulation.
Full shock absorption
Allows easier traversing of off-road obstacles. Front and rear shock absorbers provide maximum wheel traction control and a balanced ride on the ground. The full suspension bike is very comfortable and soft to ride.
Drive 1x12
This bike uses 1x12 derailleurs, which provide smooth gradation and allow effortless gear changes. The large range of gear ratios allows you to adapt the gear to your current needs.
29" wheels
The use of 29 wheels has made it possible to provide more and better tyre contact with the ground, which makes it much easier to overcome bumps when riding over difficult terrain. This size guarantees good stability when riding at higher speeds.
