The Orbea Rise H20 electric bike will support you on the trail with a Shimano EP6 motor delivering 250 W of power and a maximum torque of up to 85 Nm.

Basic data

Brand Orbea
Country of origin of the brand Spain
Sport Bicycles
Gender Male, Woman
Season Year-round
Leading colour Pink
Model/product code Rise H20 N37105V7
Purpose MTB
Code 2000066962

Frame

Frame Orbea Rise Hydro 140mm travel 29" Boost 12x148
Frame material Aluminium

Components

Steering wheel OC Mountain Control MC31, Rise20, Width 800
Handlebar width 800 mm
Handlebar material Aluminium
Handlebar support OC Mountain Control MC20, 0º
Handlebar stem material Aluminium
Depreciation Full
Fork Fox 34 Float Performance 140 3-Position QR15x110
Damper Fox Float DPS Performance 3-Position Evol custom tune 210x55mm
Saddle Fizik Taiga S-alloy rail

Drive

Type of derailleur Mechanical
Derailleurs 1x12
Number of gears 12
Rear derailleur (model) Shimano XT M8100 SGS Shadow Plus
Handles Shimano SLX M7100 I-Spec EV
Crank mechanism Shimano Steps EM600
Cassette / Freewheel Shimano CS-M7100 10-51t 12-Speed
Chain Shimano M6100

Brakes

Brakes (model) Shimano M6120 Hydraulic Disc
Brake type Hydraulic discs

Wheels

Wheel size 29"
Wheels Race Face AR 30c Tubeless Ready
Tyres Maxxis Dissector 2.40" 60 TPI 3CMaxxTerra Exo TLR / Maxxis Rekon 2.40" 120 TPI 3CMaxxTerra Exo+ TLR

Engine

Engine model Shimano EP6
Engine location Central
Engine power 250 W
Maximum torque 85 Nm

Battery

Battery capacity 540 Wh
Battery location In the frame

Additional information

Pedals included No

Warnings and producer's data

Standards, certificates CE
Warnings The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only., The maximum range of an e-bike is a conventional value, depending on factors such as weather, terrain and the weight of the user.
Producer Orbea S. Coop. | Polígono Industrial Goitondo, s/n, 48260 Mallabia, Bizkaia, Hiszpania | info@orbea.com

Orbea Rise H20 540Wh 2023 metallic mulberry/black electric bike (N37107V7)

Orbea Rise H20 2023 is a revolutionary electric bike that raises the bar for innovation and comfort. This e-MTB model redefines standards, becoming the lightest electric bike on the market. The philosophy of "more bike, less E" brings users closer to a natural trail riding experience.

The new bike model is equipped with a Shimano EP6 motor with a power output of 250 W and a 540 Wh battery integrated into the frame. This bike is perfect for those looking for support during long rides off the beaten path. Moreover, Orbea introduces an innovative battery solution that allows adding a range extender, ideal for the longest trips, or leaving it at home when not needed. This gives you the ability to customize the bike to your individual needs.

Rise H20 features a progressive full suspension that is flexible and active, providing excellent grip while maintaining control over bigger impacts. A moderately progressive curve of 22% guarantees excellent trail performance, giving the rider a natural and pleasant riding experience.

The frame made of aluminum with partially internal cable routing not only adds an aesthetic look to the bike but also increases its durability and resistance to damage. Orbea Rise H20 540Wh 2023 is a choice that will bring you joy of riding to the next level.

Orbea Rise H20 540Wh 2023 metallic mulberry/black electric bike
  1. 100%

    plGrzegorz

    Super bike

    Very comfortable and powerful drive

    Translated.Show original

Review this product

Orbea Rise H20 540Wh 2023 metallic mulberry/black electric bike

Orbea Rise H20 540Wh 2023 metallic mulberry/black electric bike

Overall rating
Please enter the order number under which you purchased this product at Sportano.

Orbea Rise H20 540Wh 2023 metallic mulberry/black electric bike

Bike assembly service available

Size Sizes table
Choose an Option...

Choose an Option

Sizes table

    Size S M L XL
    Height (cm) 150-165 160-175 170-185 180-198
    A - Seat tube (mm) 381 419 457 508
    B - Horizontal pipe (mm) 565 592 619 649
    C - Steerer tube (mm) 95 105 120 140
    D - Rear triangle (mm) 445 445 445 445
    E - Support height (mm) 336 336 336 336
    F - Support lowering (mm) 35/32 35/32 35/32 35/32
    G - Wheelbase (mm) 1180 1205 1229 1255
    H - Head angle 66/65,5 66/65,5 66/65,5 66/65,5
    I - Seat tube angle (°) 77/76,5 77/76,5 77/76,5 77/76,5
    J - Crossover (mm) 710 736 766 776
    K - Reach (mm) 425 450 474 500
    L - Stack (mm) 604 613 627 646
    M - Fork (mm) 547 547 547 547
