Orbea Urrun 40 2023 electric bike grey N33918VJ

Parameters

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.

Model/product code Urrun 40 N33918VJ

Leading colour Grey

Brand Orbea

Country of origin of the brand Spain

Gender Male, Woman

Season Year-round

Engine location Central

Engine power 250 W

Crank mechanism Shimano Steps EM600

Wheel size 29"

Frame Orbea Urrun, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing

Derailleurs 1x10

Sport Bicycles

Cassette / Freewheel Shimano CS-M4100 11-46t 10-Speed

Rear derailleur (model) Shimano Deore M5120 SGS Shadow Plus

Handles Shimano Deore M4100

Depreciation Front

Battery location In the frame

Brakes (model) Shimano MT200

Purpose MTB

Chain KMC e10 Turbo Silver

Type of derailleur Mechanical

Handlebar support Alloy forged, 35mm interface, -6º, ICR

Bar Alloy 31.6 Offset 0

Tyres Maxxis Rekon 2.40" 120 TPI 3CMaxxTerra Exo+ TLR

Frame material Aluminium

Fork SR Suntour X1 Coil LO 100mm QR

Charger Orbea 2.Generation eBike Smart charger 42V/2-4A

Engine model Shimano EP600-RS

Saddle Selle Royal Vivo 145x269mm

Steering wheel OC Mountain Control MC31, Rise20, Width 800

Brake type Hydraulic discs

Number of gears 10

Wheels Alloy, Tubeless, 29", 29c, 32H

Battery capacity 540 Wh

Stan złożenia roweru Bike adjusted and pre-assembled

Maximum torque 85 Nm

Battery type Lithium-ion

Tubeless ready wheels Yes

Axle type 148 x 12 mm, 110 x 15 mm

Frame material Aluminium

Rudders FSA 1-1/2" Integrated Aluminium Cup

Orbea Urrun 40 2023 electric bike grey N33918VJ 2

Sizes

Size	S	M	L	XL
Height (cm)	155-170	165-180	175-190	185-200
A - Seat tube (mm)	400	453	483	533
B - Horizontal pipe (mm)	565	579	608	645
C - Steerer tube (deg)	110	115	132	153
D - Rear triangle (mm)	445	445	445	445
E - Support height (mm)	322	320	320	320
F - Support lowering (mm)	54	56	56	56
G - Wheelbase (mm)	1143	1150	1173	1220
H - Head angle	65,5	66	66	66
I - Saddle angle	74,8	74,6	74,6	74,5
J - Crossover (mm)	798	826	848	882
K - Reach (mm)	395	405	440	460
L - Stack (mm)	631	628	647	666
M - Fork (mm)	533,5	533,5	533,5	533,5

Product description

Advantages

Front cushioning

The cushioning makes cycling over uneven ground much more pleasant and comfortable. This model is equipped with front suspension, which ensures safety and absorbs the force when the front wheel hits an obstacle.

Aluminium frame

The use of an aluminium frame in this model of bicycle makes it extremely light and strong, so that moving the bicycle from place to place is not a problem. In addition, this material is characterised by its resistance to deformation.

Hydraulic disc brakes

The given model of the bike is equipped with hydraulic disc brakes. This type has a very low failure rate, ensuring that the brakes will be trouble-free, even during frequent use. In addition, they feature greater braking power and modulation.

Drive 1x12

The 1x12 derailleurs used on this e-bike model guarantee smooth gradation and allow effortless gear changes. The large gear range allows you to adapt the gear to the current road conditions.

29" wheels

The use of 29 wheels has made it possible to provide more and better tyre contact with the ground, which makes it much easier to overcome bumps when riding over difficult terrain. This size guarantees good stability when riding at higher speeds."
