Orbea Alma H50 blue/red mountain bike L22016L1

Parameters

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.

Model/product code ALMA H50 L22016L1

Leading colour Navy blue

Brand Orbea

Country of origin of the brand Spain

Gender Male, Woman

Season Year-round

Crank mechanism OC1 Alloy forged Boost 32t

Wheel size 29"

Frame Orbea Alma Hydro Alloy, Boost 12x148, BSA BB, Internal cable routing

Derailleurs 1x11

Cassette / Freewheel Sun Race 11-51t 11-Speed

Sport Bicycles

Rear derailleur (model) Shimano Deore M5100 SGS Shadow Plus

Handles Shimano Deore M5100

Depreciation Front

Brakes (model) Shimano MT201 Hydraulic Disc

Chain KMC X11

Handlebar support Alloy 31.8mm interface 7º

Bar Alloy 27.2 Offset 0

Pedals included No

Tyres Maxxis Ikon 2.20" FB 60 TPI Dual

Weight of bike (estimated) 13,58 kg

Frame material Aluminium

Fork RockShox 30 Silver TK Crown adjust QR Solo Air 100

Saddle Selle Royal 2058 DRN

Steering wheel OC1 Flat 31.8mm 740mm

Brake type Hydraulic discs

Number of gears 11

Wheels Orbea Black Rock 23c Disc

Stan złożenia roweru Bike adjusted and pre-assembled

Rudders FSA 1-1/8 - 1-1/2" Integrated

Orbea Alma H50 blue/red mountain bike L22016L1 2

Orbea Alma H50 blue/red mountain bike L22016L1

Sizes

Size	S	M	L	XL
Height (cm)	155-170	165-180	178-190	185-198
A - Seat tube (mm)	400	445	483	533
B - Horizontal pipe (mm)	559	593	618	647
C - Steerer tube (deg)	90	100	110	125
D - Rear triangle (mm)	430	430	430	430
E - Support height (mm)	309	309	309	309
F - Support lowering (mm)	61	61	61	61
G - Wheelbase (mm)	1083	1118	1144	1175
H - Head angle	68	68	68	68
I - Saddle angle	74,5	74,5	74,5	74,5
J - Crossover (mm)	793	729	749	819
K - Reach (mm)	395	426	448	474
L - Stack (mm)	593	602	612	625
M - Fork (mm)	500,8	500,8	500,8	500,8

Product description

Advantages

Front cushioning

The cushioning on the bike provides comfort when negotiating bumps in the road. This model features front wheel cushioning, which absorbs the force when hitting an obstacle and increases the level of safety.

Aluminium frame

The aluminium frame is characterised by its high resistance to scratches and damage. In addition, this material is characterised by its low weight, which makes carrying the bike no problem.

Hydraulic disc brakes

This mountain bike is equipped with hydraulic disc brakes, which have a very low failure rate so that use will be trouble-free, even during frequent use. In addition, they feature greater braking power and modulation.

Drive 1x11

The 1x11 derailleurs used on this mountain bike allow effortless shifting and provide smooth gradation. The large gear range allows you to adjust the gearing to suit the current conditions on the trail.

29" wheels

The use of 29 wheels has made it possible to provide more and better tyre contact with the ground, which makes it much easier to overcome bumps when riding over rough terrain. This size guarantees good stability when riding at higher speeds."
