ATTABO GRADO 2.0 gravel bike grey

Parameters

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.

Model/product code GRADO 2.0 ATB-GR052-G

Leading colour Grey

Brand ATTABO

Country of origin of the brand Poland

Gender Male, Woman

Season Year-round

Handlebar stem material Aluminium

Crank mechanism Prowheel 42T

Grips PU wrap

Wheel size 28"

Derailleurs 1x10

Cassette / Freewheel Microshift Advent CS-H104-1148 11-48T

Sport Bicycles

Rear derailleur (model) Microshift Sword RD-G7005M

Handles Microshift Sword SB-G7000-L

Depreciation No

Handlebar material Aluminium

Handlebar width 420 mm

Fork material Aluminium

Brakes (model) TEKTRO MD-C510-F/R

Brake discs TEKTRO 160 mm

Chain KMC X10

Type of derailleur Mechanical

Handlebar support ZOOM 1-1/8" -7° / 80 mm (52 cm), 90 mm (54 cm), 100 mm (56 cm)

Bar ZOOM 27.2 mm

Pedals included Yes

Tyres Kenda PIEDMONT 700x40C

Weight of bike (estimated) 11,7 kg (56 cm), 11,6 kg (52 cm), 11,6 kg (54 cm)

Frame material Aluminium

spokes 14 G

Saddle DDK-3255

Steering wheel ZOOM, Reach 80 mm, Drop 124 mm

Brake type Mechanical discs

Number of gears 10

Suport On machine bearings

Wheels Aluminium, double-chamber 32H

Folding condition of the bike Bicycle for self-assembly

Hubs Shimano HB-QC300, Shimano FH-QC300-HM

Frame material Aluminium

Rudders NECO 1-1/8" semi-integrated

Sizes table

Below you will find information that will help you choose the right size when purchasing a Grado 2.0 bike from ATTABO.

Frame size	52	54	56
Wheel size	28	28	-
Height (cm)	170-175	172-178	180-188
Weight (kg)	11,6	11,6	11,7
A	70	71	72
B Head tube height (mm)	130	130	130
C REACH	380	390	400
D STACK	560	580	600
E BB DROP	70	70	70
F Height of handlebars (mm)	940	950	960
G Length of top tube measured horizontally (mm)	537	551	565
H Wheels base (mm)	1045	1050	1055
I Seat tube angle (°)	74,5	74,5	74,5
Section height (mm)	790	810	830
Saddle height range (mm)	870-1090	890-1110	910-1130
Crank arm length (mm)	170	170	170

Product description

Advantages

Aluminium frame

This bike model has been made with the right materials to ensure maximum comfort. Durable aluminium was used for the frame, which stands out for its lightness. In addition, this material is characterised by a high strength index and resistance to bending.

28" wheels

The 28-inch wheels are characterised by prolonged wear and allow faster speeds, which are far easier to maintain. Compared to smaller sizes, these wheels provide better stability at higher speeds.

Mechanical disc brakes

This model of bike uses mechanical disc brakes, which have a low failure rate and high braking power. This type, thanks to its simple design, guarantees ease of eventual servicing.
