Orbea Oiz H10 is a bike for true mountain adventure enthusiasts. Designed with optimal comfort and performance in mind, it performs well both on challenging trails and in everyday riding. It is a combination of innovation and solidity at the highest level.

Basic data

Brand Orbea
Country of origin of the brand Spain
Sport Bicycles
Gender Male, Woman
Season Year-round
Leading colour White
Model/product code Oiz H10 R23209N5
Code 2000103864

Frame

Frame Orbea Oiz Hydro High Polished, Alloy link, Boost, BSA, SIC, UFO, I-Line shock
Frame material Aluminium

Components

Steering wheel OC Mountain Performance MP30, Width 760
Handlebar support OC Mountain Performance MP21, -6º
Grips OC Lock On
Depreciation Full
Rudders Alloy 1-1/2", Black Oxidated Bearing
Fork Fox 34 Float SC Performance 120 Grip Remote Push to Lock QR15x110
Damper Fox Float SL Performance 120mm Remote Push-lock Evol custom tune190x45mm
Saddle Selle Italia Model X FecAlloy Rail 145x248mm
Bar OC Mountain Control MC21, 31.6mm, Dropper

Drive

Derailleurs 1x12
Number of gears 12
Rear derailleur (model) Shimano XT M8100 SGS Shadow Plus
Handles Shimano XT M8100 I-Spec EV
Crank mechanism Shimano XT M8100 32t
Cassette / Freewheel Shimano CS-M7100 10-51t 12-Speed
Chain Shimano M6100

Brakes

Brakes (model) Shimano M6100 Hydraulic Disc
Brake type Hydraulic discs

Wheels

Wheel size 29"
Wheels Race Face AR 30c Tubeless Ready
Tyres Maxxis Rekon Race 2.40" WT 120 TPI Exo TLR

Warnings and producer's data

Warnings The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.
Producer Orbea S. Coop. | Polígono Industrial Goitondo, s/n, 48260 Mallabia, Bizkaia, Hiszpania | info@orbea.com

Orbea Oiz H10 2024 white chic/shadow coral mountain bike (R23209N5)

Orbea Oiz H10 2024 is a mountain bike that impresses with its modern technology, excellent performance, and exceptional riding comfort. Its carefully designed construction and advanced specifications make it the ideal choice for the most demanding mountain bikers. With this model, you can count on reliability and precision in all terrain conditions, allowing you to fully enjoy every adventure on the trail.

The bike stands out for its exceptional lightness and excellent performance, thanks to the use of a frame made from high-quality aluminum with a High Polished finish. This advanced construction makes the bike one of the lightest in the XC category. The lightness of the frame is crucial for a cross-country bike, enabling easier maneuvering, faster acceleration, and minimizing fatigue during long rides. Thanks to this, the bike meets the expectations of even the most demanding mountain bikers.

The Orbea Oiz frame is additionally equipped with advanced technologies. Boost increases rear axle stiffness, which translates into better stability and control while riding. The BSA system ensures reliable bottom bracket mounting, while the SIC and UFO technologies optimize frame stiffness and reduce vibrations, improving riding comfort. The I-Line shock absorber, integrated with the frame, guarantees smooth riding even on the toughest trails, while providing maximum comfort.

Absorbing all vibrations and terrain irregularities is the responsibility of the Fox 34 Float SC Performance 120 Grip Remote Push to Lock QR15x110 fork, a key component of the Oiz H10. This fork offers a 120 mm travel, providing excellent shock absorption and terrain irregularity damping. Thanks to the Grip Remote Push to Lock technology, the rider can easily adjust the shock settings to achieve optimal performance in any conditions. Additionally, the quick release QR15x110 facilitates fast and secure wheel mounting, which is invaluable during tire changes or servicing.

The Fox Float SL Performance damper is an integral part of the advanced suspension system. Remote Push-lock technology allows easy locking and unlocking of the damper while riding, enabling adjustment of suspension performance to changing terrain conditions. Additionally, Evol technology (Extra Volume) increases the air chamber volume, providing smoother and more controlled riding, especially on demanding, technical trail sections.

This model performs well both in XC races, marathons, and on light trails. It offers fast and enjoyable descents as well as light and efficient climbs, being a no-compromise XC machine that also delivers plenty of riding fun. Its versatility makes it the perfect choice for riders looking for a bike that can handle any terrain conditions.

Advantages

Aluminium frame
When designing this bike, the focus was on selecting the right materials to ensure the highest quality. Therefore, the frame is made of aluminium, which combines durability and low weight.
Hydraulic disc brakes
This mountain bike model uses hydraulic disc brakes, which have a very low failure rate, so they will be trouble-free even during frequent use. The undoubted advantage is greater braking power and modulation.
Full shock absorption
Allows easier traversing of off-road obstacles. Front and rear shock absorbers provide maximum wheel traction control and a balanced ride on the ground. The full suspension bike is very comfortable and soft to ride.
Drive 1x12
This bike uses 1x12 derailleurs, which provide smooth gradation and allow effortless gear changes. The large range of gear ratios allows you to adapt the gear to your current needs.
29" wheels
The use of 29 wheels has made it possible to provide more and better tyre contact with the ground, which makes it much easier to overcome bumps when riding over difficult terrain. This size guarantees good stability when riding at higher speeds.
Orbea Oiz H10 2024 white chic/shadow coral mountain bike
Feedback

There are no reviews yet, be the first!

Review this product

Orbea Oiz H10 2024 white chic/shadow coral mountain bike

Orbea Oiz H10 2024 white chic/shadow coral mountain bike

Overall rating
Please enter the order number under which you purchased this product at Sportano.

Orbea Oiz H10 2024 white chic/shadow coral mountain bike

No opinion

Bike assembly service available

Size Sizes table
Choose an Option...

Choose an Option

Sizes table

    Size S M L XL
    Height (cm) 155-170 165-180 178-190 185-198
    A - Seat tube (mm) 410 432 460 510
    B - Horizontal pipe (mm) 568 594 619 645
    C - Steerer tube (mm) 90 95 105 115
    D - Rear triangle (mm) 436 436 436 436
    E - Support height (mm) 333 333 333 333
    F - Support lowering (mm) 42 42 42 42
    G - Wheelbase (mm) 1142 1169 1195 1223
    H - Head angle 67 67 67 67
    I - Seat tube angle (°) 76,5 76,5 76,5 76,5
    J - Crossover (mm) 729 743 746 743
    K - Reach (mm) 425 450 472 496
    L - Stack (mm) 596 600 610 619
    M - Fork (mm) 531 531 531 531
