Basic data

Sport Bicycles
Brand Orbea
Leading colour Green
Season Year-round
Model/product code Laufey H10 R25007P8
Gender Male, Woman
Country of origin of the brand Spain
Code 2000096392

Frame

Frame Orbea Laufey Hydro Triple Butted 29" Boost 12x148 ISCG 05
Frame material Aluminium

Components

Steering wheel OC Mountain Control MC30, Rise20, Width 800
Handlebar support Alloy 3D forged, 35mm interface, -7º
Grips OC Lock On
Depreciation Front
Rudders Acros Alloy 1-1/8 - 1-1/2" Integrated
Fork Marzocchi Bomber Z2 140 QR15x110
Saddle Selle Royal 2058 DRN
Bar OC Mountain Control MC21, 31.6mm, Dropper

Drive

Derailleurs 1x12
Number of gears 12
Rear derailleur (model) Shimano SLX M7100 SGS Shadow Plus
Handles Shimano Deore M6100 I-Spec EV
Crank mechanism Shimano MT512 32t
Cassette / Freewheel Shimano CS-M6100 10-51t 12-Speed
Chain Shimano M6100

Brakes

Brakes (model) Shimano M6100 Hydraulic Disc
Brake type Hydraulic discs

Wheels

Wheel size 29"
Wheels Alloy, Tubeless, 29″, 29c, 32H
Tyres Maxxis Dissector 2.60″ 60 TPI Exo TLR

Warnings and producer's data

Warnings The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.
Producer Orbea S. Coop. | Polígono Industrial Goitondo, s/n, 48260 Mallabia, Bizkaia, Hiszpania | [email protected]

Other data

Service label Bike assembly service available

Orbea Laufey H10 2024 metallic olive green/titanium black mountain bike (R25007P8)

Advantages

Front cushioning
The cushioning on the bike provides comfort when negotiating bumps in the road. This model features front wheel cushioning, which absorbs the force when hitting an obstacle and increases the level of safety.
Aluminium frame
The aluminium frame is characterised by its high resistance to scratches and damage. In addition, this material is characterised by its low weight, which makes carrying the bike no problem.
Hydraulic disc brakes
This mountain bike is equipped with hydraulic disc brakes, which have a very low failure rate so that use will be trouble-free, even during frequent use. In addition, they feature greater braking power and modulation.
Tubeless ready tyres
Tyres made using the TLR (Tubeless Ready) system are resistant to punctures and allow the use of lower pressures. In addition, this technology eliminates the problem of so-called Snake Bite, i.e. punctures in the inner tube caused by pinching against the rim.
Drive 1x12
The 1x12 derailleurs used on this mountain bike allow effortless shifting and provide smooth gradation. The large gear range allows you to adjust the gearing to suit the current conditions on the trail.
29" wheels
The use of 29 wheels has made it possible to provide more and better tyre contact with the ground, which makes it much easier to overcome bumps when riding over rough terrain. This size guarantees good stability when riding at higher speeds.
Orbea Laufey H10 2024 metallic olive green/titanium black mountain bike
UVEX bike helmet Viva 3 black S4109840115
Size
52-57 cm
56-62 cm
Choose an Option...

Choose an Option

  • 52-57 cm €66.99 €59.99
  • 56-62 cm €66.99 €59.99
Add to Wish List
CamelBak Podium bicycle bottle black 1875001071
Size
710 ml
Choose an Option...

Choose an Option

  • 710 ml €14.99
Add to Wish List
Elite Custom Race+ bidon basket black EL0140640
Size
OS
Choose an Option...

Choose an Option

  • OS €15.99
Add to Wish List
Bike stand Orbea Onna/MX black
Size
27.5"-29"
Choose an Option...

Choose an Option

  • 27.5"-29" €42.99
Add to Wish List
Feedback

There are no reviews yet, be the first!

Review this product

Orbea Laufey H10 2024 metallic olive green/titanium black mountain bike

Orbea Laufey H10 2024 metallic olive green/titanium black mountain bike

Overall rating
Please enter the order number under which you purchased this product at Sportano.

Orbea Laufey H10 2024 metallic olive green/titanium black mountain bike

No opinion

Bike assembly service available

Size Sizes table
Choose an Option...

Choose an Option

Sizes table

    Below you will find information that will help you choose the right size when buying a Laufey H10 2024 bike by Orbea.

    Size S M L XL
    Height (cm) 150-165 160-175 170-185 180-198
    A - Seat tube (mm) 380 415 430 460
    B - Horizontal pipe (mm) 572 598 625 652
    C - Steerer tube (mm) 95 105 120 130
    D - Rear triangle (mm) 440 440 440 440
    E - Support height (mm) 310 310 310 310
    F - Support lowering (mm) 65 65 65 65
    G - Wheelbase (mm) 1181,8 1210,1 1240,6 1269,9
    H - Head angle 64,5 64,5 64,5 64,5
    I - Seat tube angle (°) 77 77 77 77
    J - Crossover (mm) 770 770 770 770
    K - Reach (mm) 427 451 475 500
    L - Stack (mm) 633 642 655,5 664,5
    M - Fork (mm) 554 554 554 554
