Orbea Orca M40 2023 sulfur yellow/night black road bike (N10655A2)

Frame

Frame Orbea Orca carbon OMR Disc, monocoque construction, HS 1,5", BB 386mm, powermeter compatible, Rear Thru Axle 12x142mm

Frame material Carbon fibre

Components

Steering wheel OC RP30-R Road Performance Riser, Reach 70, Drop 125, Rise 15, Flare 5º

Handlebar support OC Road Performance RP21, -6º

Fork Orbea carbon fork 2021, aluminium steerer, 1-1/8" head tube

Fork material Carbon fibre

Saddle Fizik Aliante R5

Bar OC2 Carbon 27.2 Offset 20

Drive

Type of derailleur Mechanical

Derailleurs 2x10

Number of gears 20

Front derailleur (model) Shimano Tiagra 4700

Rear derailleur (model) Shimano Tiagra 4700 GS

Handles Shimano Tiagra ST-4770

Crank mechanism Shimano Tiagra 4700 34x50t

Cassette / Freewheel Shimano Tiagra HG-500 11-34t 10-Speed

Chain KMC X10

Brakes

Brakes (model) Shimano Tiagra 4770 Hydraulic Disc

Brake type Hydraulic discs

Wheels

Wheel size 28"

Wheels ORBEA R19 ALLOY TLR

Tyres Vittoria Zafiro V Rigid bead 700x28c

Hubs Orbea Thru Axle 12x100mm M12x2 P1 Solid - front hub, Orbea Thru Axle 12x142mm M12x2 P1 Solid - rear hub

Additional information

Folding condition of the bike Bike adjusted and pre-assembled

Other data

Sport Bicycles

Brand Orbea

Leading colour Yellow

Season Year-round

Model/product code Orca M40 N10655A2

Gender Male, Woman

Country of origin of the brand Spain

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.

Type of Product Endurance

Code 2000066778

Size	51	53	55	57
Height (cm)	167-172	173-179	180-185	186-191
A - Seat tube (mm)	480	500	520	540
B - Horizontal pipe (mm)	535	548	560	576
C - Steerer tube (mm)	130	148	168	186
D - Rear triangle (mm)	408	408	408	408
E - Support height (mm)	267	269	269	269
F - Support lowering (mm)	72	70	70	70
G - Wheelbase (mm)	980	481	991	1002
H - Head angle	72,2	72,8	73	73,2
I - Seat tube angle (°)	73,7	73,5	73,5	73,2
J - Crossover (mm)	766	787	807	825
K - Reach (mm)	377	382	388	395
L - Stack (mm)	540	559	579	597
M - Fork (mm)	370	370	370	370

Advantages

Carbon frame

The frame of this road bike has been made from extremely lightweight carbon, so carrying the bike is not a problem. Carbon is distinguished by the fact that it is very effective in reducing the force of vibrations generated when riding over rough terrain.

Hydraulic disc brakes

This road bike is equipped with hydraulic disc brakes, which have an extremely low failure rate, ensuring trouble-free use, even during frequent use. In addition, they are distinguished by their greater braking power and modulation.

28" wheels

The use of 28-inch wheels on this model has made the bike faster to reach higher speeds and much easier to maintain. This wheel size allows the bike to negotiate obstacles comfortably and provides better stability at higher speeds.

Carbon fork

The fork on this bike is made of carbon, which is characterised by its extreme lightness and ability to absorb the power generated when riding over rough terrain. This material combines strength and low weight.
