Frame
Frame Orbea Rise Evo OMR 2023, 140mm travel, 29" wheels, Concentric Boost 12x148
Frame material Carbon fibre
Components
Steering wheel OC Mountain Control MC10 Carbon, Rise 20, Width 800
Handlebar width 800 mm
Handlebar material Carbon fibre
Handlebar support OC Mountain Control MC10 Alu SL, 0º
Handlebar stem material Aluminium
Depreciation Full
Fork Fox 36 Float Factory 150 Grip2 QR15x110 Kashima
Saddle Fizik Taiga Kium rail
Bar Fox Transfer Factory Kashima Dropper 31.6
Drive
Type of derailleur Mechanical
Derailleurs 1x12
Number of gears 12
Rear derailleur (model) Shimano XT M8150 SGS Shadow Plus
Handles Shimnano M8150
Crank mechanism Shimano Steps EM900
Cassette / Freewheel Shimano CS-M8100 10-51t 12-Speed
Chain Shimano M8100 12s
Brakes
Brakes (model) Shimano XT M8120 Hydraulic Disc
Brake type Hydraulic discs
Wheels
Wheel size 29"
Wheels OQUO Mountain Control MC32LTD Carbon
Tyres TYRES Maxxis Dissector 2.40" 60 TPI 3CMaxxTerra Exo TLR
Axle type 12x148/15x110
Hubs Fox Kabolt Boost front hub
Additional information
Pedals included No
Folding condition of the bike Bike adjusted and pre-assembled
Other data
Sport Bicycles
Brand Orbea
Leading colour Green
Season Year-round
Model/product code Rise M-Team N37605V1
Purpose MTB
Gender Male, Woman
Country of origin of the brand Spain
Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only., The maximum range of an e-bike is a conventional value, depending on factors such as weather, terrain and the weight of the user.
Code 2000066786
Engine model Shimano EP8
Engine location Central
Engine power 250 W
Maximum torque 85 Nm
Battery capacity 360 Wh
Battery location In the frame
| Size | S | M | L | XL |
| Height (cm) | 150-165 | 160-175 | 170-185 | 180-198 |
| A - Seat tube (mm) | 381 | 419 | 457 | 508 |
| B - Horizontal pipe (mm) | 565 | 592 | 619 | 649 |
| C - Steerer tube (mm) | 95 | 105 | 120 | 140 |
| D - Rear triangle (mm) | 445 | 445 | 445 | 445 |
| E - Support height (mm) | 336 | 336 | 336 | 336 |
| F - Support lowering (mm) | 35/32 | 35/32 | 35/32 | 35/32 |
| G - Wheelbase (mm) | 1180 | 1205 | 1229 | 1255 |
| H - Head angle | 66/65,5 | 66/65,5 | 66/65,5 | 66/65,5 |
| I - Seat tube angle (°) | 77/76,5 | 77/76,5 | 77/76,5 | 77/76,5 |
| J - Crossover (mm) | 710 | 736 | 766 | 776 |
| K - Reach (mm) | 425 | 450 | 474 | 500 |
| L - Stack (mm) | 604 | 613 | 627 | 646 |
| M - Fork (mm) | 547 | 547 | 547 | 547 |
Advantages
Carbon frame
The use of a carbon frame on this model of bike makes it extremely light and resilient, making use much more comfortable. In addition, the carbon frame effectively dampens vibrations when negotiating bumps.
Hydraulic disc brakes
The given model of the bike is equipped with hydraulic disc brakes. This type has a very low failure rate, ensuring that the brakes will be trouble-free, even during frequent use. In addition, they feature greater braking power and modulation.
Tubeless ready tyres
Thanks to the use of Tubeless Ready (TLR) technology, the tyres are resistant to punctures and lower pressures can be applied. Furthermore, the system eliminates the problem of ‘Snake Bite’, i.e. puncturing the inner tube by pinching against the rim.
Full shock absorption
Full suspension, i.e. both the front and rear wheels, allows you to negotiate obstacles in difficult terrain more comfortably. A bike with full suspension provides more grip and efficiency.
Drive 1x12
The 1x12 derailleurs used on this e-bike model guarantee smooth gradation and allow effortless gear changes. The large gear range allows you to adapt the gear to the current road conditions.
29" wheels
The use of 29’ wheels allows for greater and better tyre contact with the ground, making it much easier to overcome bumps when riding over rough terrain. This size guarantees good stability when riding at higher speeds.
