Basic data

Sport Bicycles
Brand Orbea
Leading colour Purple
Season Year-round
Model/product code Rallon M20 N26707LP
Gender Male, Woman
Country of origin of the brand Spain
Code 2000066781

Frame

Frame Orbea Monocoque Race Carbon. Advanced Dynamics 160mm suspension technology. Concentric Boost 12x148 rear axle
Frame material Carbon fibre

Components

Steering wheel OC Mountain Control MC30, Rise20, Width 800
Handlebar support OC1 3D Forged 35mm interface 7º
Depreciation Full
Fork Fox 38 Float Performance 170 Grip 3-Position QR15x110
Damper Fox FLOAT X Performance 2-Position Evol LV custom tune 230x60mm
Saddle Fizik Taiga S-alloy rail
Bar OC MC20 Mountain Control Dropper, 31,6mm

Drive

Derailleurs 1x12
Number of gears 12
Rear derailleur (model) Shimano SLX M7100 SGS Shadow Plus
Handles Shimano SLX M7100 I-Spec EV
Crank mechanism Race Face Aeffect 32t
Cassette / Freewheel Shimano CS-M7100 10-51t 12-Speed
Chain Shimano M6100

Brakes

Brakes (model) Shimano M6120 Hydraulic Disc
Brake type Hydraulic discs

Wheels

Wheel size 29"
Wheels Race Face AR 30c Tubeless Ready
Tyres Maxxis Assegai 2.50" WT FB 120 TPI 3C Maxx Terra EXO+ TR

Warnings and producer's data

Warnings The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.
Producer Orbea S. Coop. | Polígono Industrial Goitondo, s/n, 48260 Mallabia, Bizkaia, Hiszpania | [email protected]

Other data

Service label Bike assembly service available

Orbea Rallon M20 2023 metallic mulberry mountain bike (N26705LP)

Advantages

Carbon frame
When designing this bike, the focus was on selecting the right materials to ensure the highest quality. Therefore, the frame is made of carbon, which combines lightness and resilience in addition to effectively damping vibrations.
Hydraulic disc brakes
This mountain bike model uses hydraulic disc brakes, which have a very low failure rate, so they will be trouble-free even during frequent use. The undoubted advantage is greater braking power and modulation.
Full shock absorption
Allows easier traversing of off-road obstacles. Front and rear shock absorbers provide maximum wheel traction control and a balanced ride on the ground. The full suspension bike is very comfortable and soft to ride.
Drive 1x12
This bike uses 1x12 derailleurs, which provide smooth gradation and allow effortless gear changes. The large range of gear ratios allows you to adapt the gear to your current needs.
29" wheels
The use of 29 wheels has made it possible to provide more and better tyre contact with the ground, which makes it much easier to overcome bumps when riding over difficult terrain. This size guarantees good stability when riding at higher speeds.
Orbea Rallon M20 2023 metallic mulberry mountain bike
UVEX bike helmet Viva 3 black S4109840115
Size
52-57 cm
56-62 cm
Choose an Option...

Choose an Option

  • 52-57 cm €66.99 €59.99
  • 56-62 cm €66.99 €59.99
Add to Wish List
CamelBak Podium Chill bicycle bottle 710 ml black
Size
710 ml
Choose an Option...

Choose an Option

  • 710 ml €19.99
Add to Wish List
Elite bicycle kit Custom Race Plus basket + Elite Fly Tex Maillot Jaune 550 ml bottle black
Size
550 ml
Choose an Option...

Choose an Option

  • 550 ml €23.99 €21.99
Add to Wish List
Bike stand Orbea Onna/MX black
Size
27.5"-29"
Choose an Option...

Choose an Option

  • 27.5"-29" €42.99
Add to Wish List
Feedback

There are no reviews yet, be the first!

Review this product

Orbea Rallon M20 2023 metallic mulberry mountain bike

Orbea Rallon M20 2023 metallic mulberry mountain bike

Overall rating
Please enter the order number under which you purchased this product at Sportano.

Orbea Rallon M20 2023 metallic mulberry mountain bike

No opinion

Bike assembly service available

Size Sizes table
Choose an Option...

Choose an Option

Sizes table

    Below you will find information that will help you choose the right size when buying a Rallon M20 bike from Orbea.

    Size M XL
    Height (cm) 160-180 180-200
    A - Seat tube (mm) 415 460
    B - Horizontal pipe (mm) 600 655
    C - Steerer tube (mm) 100 120
    D - Rear triangle (mm) 438 438
    E - Support height (mm) 343 343
    F - Support lowering (mm) 35 35
    G - Wheelbase (mm) 1230 1289
    H - Head angle 64/63,5 64/63,5
    I - Seat tube angle (°) 77 77
    J - Crossover (mm) 744 781
    K - Reach (mm) 455 505
    L - Stack (mm) 632 650
    M - Fork (mm) 587,7 587,7
