EcoBike Rhino/Rhino LG 16 Ah Smart BMS electric bike black 1010203

Parameters

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only., The maximum range of an e-bike is a conventional value, depending on factors such as weather, terrain and the weight of the user.

Model/product code Rhino/Rhino LG 16 Ah Smart BMS el. 1010203

Leading colour Black

Brand EcoBike

Country of origin of the brand Poland

Gender Male, Woman

Season Year-round

Engine location Hub

Engine power 250 W

Crank mechanism Prowheel 46T

Wheel size 20"

Derailleurs 1x6

Sport Bicycles

Cassette / Freewheel Shimano MF-TZ500 14-28T 6

Rear derailleur (model) Shimano Tourney 6-speed

Handles Shimano Tourney Revo 6

Depreciation Front

Battery location In the frame

Brakes (model) Tektro MD M300

Purpose City/urban

Maximum range 140 km

Chain KMC

Type of derailleur Mechanical

Handlebar support Zoom 9° / 70 mm

Bar Promax 30.4 / 350 mm

Tyres Schwalbe Big Apple 20 x 2.0

Frame material Aluminium

Fork RST CARVE-D-20, 50 mm

Engine model Bafang

Saddle Selle Royal Freeway

Weight of bike (estimated) 23,3 kg

Steering wheel Promax 640 mm 25.4

Maximum engine power 320 W

Brake type Mechanical discs

Number of gears 6

Wheels Reinforced three-chamber wheels

Battery capacity 16Ah

Stan złożenia roweru Bike adjusted and pre-assembled

Maximum torque 32 Nm

Battery type Lithium-ion

EcoBike Rhino/Rhino LG 16 Ah Smart BMS electric bike black 1010203 2

Sizes

Frame size	15,5"
Height (cm)	155-185
A - Rura pozioma (mm)	619,9
B - Rura sterowa (mm)	135
C - Rura podsiodłowa (mm)	365
D - Wheel base (mm)	1093,6
E - Kąt siodełka (°)	73
F - Kąt główki (°)	72,5

Product description

Advantages

Front cushioning

The cushioning makes cycling over uneven ground much more pleasant and comfortable. This model is equipped with front suspension, which ensures safety and absorbs the force when the front wheel hits an obstacle.

Aluminium frame

The use of an aluminium frame in this model of bicycle makes it extremely light and strong, so that moving the bicycle from place to place is not a problem. In addition, this material is characterised by its resistance to deformation.

Mechanical disc brakes

A given model of bicycle is equipped with mechanical disc brakes. This type is characterised by high braking power and very low failure rate. Their simple design guarantees ease of possible repair.
