Orbea Oiz H30 2023 blue mountain bike N23209N3 (N23207N3)

Frame

Frame Orbea Oiz Hydro High Polished, Alloy link, Boost, PF BB, UFO2, I-Line shock

Frame material Aluminium

Components

Steering wheel OC1 Flat 31.8mm 740mm

Handlebar support OC Mountain Performance MP21 Stem, -6º

Depreciation Full

Rudders FSA 1-1/2" Integrated Aluminium Cup

Fork Fox 32 Float Rhythm 120 Remote Push-Unlock QR15x110

Damper Fox i-line DPS Performance 120mm Remote Push-Unlock Evol custom tune190x45mm

Saddle Selle Italia Model X FecAlloy Rail 145x248mm

Bar Alloy 31.6x400mm Offset 0

Drive

Type of derailleur Mechanical

Derailleurs 1x12

Number of gears 12

Rear derailleur (model) Shimano Deore M6100 SGS Shadow Plus

Handles Shimano Deore M6100

Crank mechanism Shimano MT511 32t

Cassette / Freewheel Shimano CS-M6100 10-51t 12-Speed

Chain Shimano M6100

Brakes

Brakes (model) Shimano MT201 Hydraulic Disc

Brake type Hydraulic discs

Wheels

Wheel size 29"

Wheels Orbea OC1 25c

Tyres Maxxis Ikon 2.20" FB 60 TPI Dual

Tubeless ready wheels Yes

Tubeless ready tyres Yes

Additional information

Lighting No

Mudguards No

Luggage carrier No

Folding condition of the bike Bike adjusted and pre-assembled

Other data

Sport Bicycles

Brand Orbea

Leading colour Blue

Season Year-round

Model/product code Oiz H30 2023 N23209N3

Purpose MTB

Gender Male, Woman

Country of origin of the brand Spain

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.

Code 2000059067

Size	S	M	L	XL
Height (cm)	155-170	165-180	178-190	185-198
A - Seat tube (mm)	410	432	460	510
B - Horizontal pipe (mm)	568	594	619	645
C - Steerer tube (mm)	90	95	105	115
D - Rear triangle (mm)	436	436	436	436
E - Support height (mm)	333	333	333	333
F - Support lowering (mm)	42	42	42	42
G - Wheelbase (mm)	1142	1169	1195	1223
H - Head angle	67	67	67	67
I - Seat tube angle (°)	76,5	76,5	76,5	76,5
J - Crossover (mm)	729	743	746	743
K - Reach (mm)	425	450	472	496
L - Stack (mm)	596	600	610	619
M - Fork (mm)	531	531	531	531

Advantages

Aluminium frame

When designing this bike, the focus was on selecting the right materials to ensure the highest quality. Therefore, the frame is made of aluminium, which combines durability and low weight.

Hydraulic disc brakes

This mountain bike model uses hydraulic disc brakes, which have a very low failure rate, so they will be trouble-free even during frequent use. The undoubted advantage is greater braking power and modulation.

Tubeless ready tyres

The use of TLR (Tubeless Ready) technology has made it possible to use lower pressures and makes the tyres resistant to punctures. What's more, the system rules out the problem of ‘Snake Bite’, i.e. puncturing the inner tube by pinching it against the rim.

Full shock absorption

Allows easier traversing of off-road obstacles. Front and rear shock absorbers provide maximum wheel traction control and a balanced ride on the ground. The full suspension bike is very comfortable and soft to ride.

Drive 1x12

This bike uses 1x12 derailleurs, which provide smooth gradation and allow effortless gear changes. The large range of gear ratios allows you to adapt the gear to your current needs.

29" wheels

The use of 29 wheels has made it possible to provide more and better tyre contact with the ground, which makes it much easier to overcome bumps when riding over difficult terrain. This size guarantees good stability when riding at higher speeds.
