Aluminum frame, full suspension, and high-quality Shimano components – all of this makes up the efficient mountain bike Orbea Oiz H10.

Basic data

Brand Orbea
Country of origin of the brand Spain
Sport Bicycles
Gender Male, Woman
Season Year-round
Leading colour Blue
Model/product code Oiz H10 N23407N3
Purpose MTB
Code 2000054526

Frame

Frame Orbea Oiz Hydro High Polished, Alloy link, Boost, PF BB, UFO2, I-Line shock
Frame material Aluminium

Components

Steering wheel Alloy, 31.8mm, Flat, 740mm, Sweep 9
Handlebar support OC Mountain Performance MP21, -6º
Depreciation Full
Rudders Acros Alloy 1-1/2" Internal Cable Routing
Fork Fox 34 Float SC Performance 120 Grip Remote Push-Unlock QR15x110
Damper Fox i-line DPS Performance 120mm Remote Push-Unlock Evol custom tune190x45mm
Saddle Selle Italia Model X FecAlloy Rail 145x248mm
Bar OC Mountain Control MC20, 31.6mm, Dropper

Drive

Derailleurs 1x12
Number of gears 12
Rear derailleur (model) Shimano XT M8100 SGS Shadow Plus
Handles Shimano XT M8100 I-Spec EV
Crank mechanism Shimano XT M8100 32t
Cassette / Freewheel Shimano CS-M7100 10-51t 12-Speed
Chain Shimano M6100

Brakes

Brakes (model) Shimano M6100 Hydraulic Disc
Brake type Hydraulic discs

Wheels

Wheel size 29"
Wheels Race Face AR 30c Tubeless Ready
Tyres Maxxis Forekaster 2.35" FB 120 TPI Dual Exo, Maxxis Rekon Race 2.35" 120 TPI Exo TLR
Axle type 148 x 12 mm, 110 x 15 mm
Tubeless ready wheels Yes
Tubeless ready tyres Yes

Additional information

Lighting No
Mudguards No
Luggage carrier No

Warnings and producer's data

Warnings The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.
Producer Orbea S. Coop. | Polígono Industrial Goitondo, s/n, 48260 Mallabia, Bizkaia, Hiszpania | info@orbea.com

Orbea Oiz H10 blue-orange 2023 mountain bike N23405N3 (N23407N3)

Orbea Oiz H10 is a mountain bike for demanding users who expect high-quality equipment. Designed for XC racing and sporty riding, it is also an excellent choice for recreational trips on mountainous, varied terrain.

The frame of the bike is made of aluminum and has a polished surface that gives it an elegant look. The frame was designed to provide the best possible performance on difficult terrain, as well as to minimize weight, making the bike very light and agile. The steep seat tube and lower stack give you space behind the handlebars and full control over the ride.

Orbea Oiz H10 features a rear shock Fox i-line DPS Performance with 120mm travel, equipped with a remote lockout function. This allows the bike to tackle even the toughest trails while providing a high level of comfort and reducing the risk of damage. Full suspension will perfectly absorb shocks and overcome bumps you may encounter on your path.

The 29-inch wheels and Maxxis Forekaster and Maxxis Rekon Race tires provide excellent grip and cornering, and thanks to the EXO reinforcement on the sides, they also feature increased resistance to abrasion.

This model is equipped with a precise and reliable Shimano drivetrain, consisting of 12 gears and a Shimano XT M8100 32t crankset. This ensures smooth and precise gear shifts, allowing users to easily adjust speed to trail conditions.

Advantages

Aluminium frame
When designing this bike, the focus was on selecting the right materials to ensure the highest quality. Therefore, the frame is made of aluminium, which combines durability and low weight.
Hydraulic disc brakes
This mountain bike model uses hydraulic disc brakes, which have a very low failure rate, so they will be trouble-free even during frequent use. The undoubted advantage is greater braking power and modulation.
Tubeless ready tyres
The use of TLR (Tubeless Ready) technology has made it possible to use lower pressures and makes the tyres resistant to punctures. What's more, the system rules out the problem of ‘Snake Bite’, i.e. puncturing the inner tube by pinching it against the rim.
Full shock absorption
Allows easier traversing of off-road obstacles. Front and rear shock absorbers provide maximum wheel traction control and a balanced ride on the ground. The full suspension bike is very comfortable and soft to ride.
Drive 1x12
This bike uses 1x12 derailleurs, which provide smooth gradation and allow effortless gear changes. The large range of gear ratios allows you to adapt the gear to your current needs.
29" wheels
The use of 29 wheels has made it possible to provide more and better tyre contact with the ground, which makes it much easier to overcome bumps when riding over difficult terrain. This size guarantees good stability when riding at higher speeds.
Orbea Oiz H10 blue-orange 2023 mountain bike N23405N3
Feedback

There are no reviews yet, be the first!

Review this product

Orbea Oiz H10 blue-orange 2023 mountain bike N23405N3

Orbea Oiz H10 blue-orange 2023 mountain bike N23405N3

Overall rating
Please enter the order number under which you purchased this product at Sportano.

Orbea Oiz H10 blue-orange 2023 mountain bike N23405N3

No opinion

Bike assembly service available

Size Sizes table
Choose an Option...

Choose an Option

Sizes table

    Size S M L XL
    Height (cm) 155-170 165-180 178-190 185-198
    A - Seat tube (mm) 410 432 460 510
    B - Horizontal pipe (mm) 568 594 619 645
    C - Steerer tube (mm) 90 95 105 115
    D - Rear triangle (mm) 436 436 436 436
    E - Support height (mm) 333 333 333 333
    F - Support lowering (mm) 42 42 42 42
    G - Wheelbase (mm) 1142 1169 1195 1223
    H - Head angle 67 67 67 67
    I - Seat tube angle (°) 76,5 76,5 76,5 76,5
    J - Crossover (mm) 729 743 746 743
    K - Reach (mm) 425 450 472 496
    L - Stack (mm) 596 600 610 619
    M - Fork (mm) 531 531 531 531
