Orbea Occam M30 green mountain bike M25615LT (M25615LT)

Frame

Frame Orbea Occam OMR 150mm skok 29" C-Boost 12x148

Frame material Carbon fibre

Components

Steering wheel OC1 35mm 12mm Rise 780mm

Handlebar material Aluminium

Handlebar support OC1 3D kuty 35mm interfejs 7º

Handlebar stem material Aluminium

Depreciation Full

Rudders Acros Alloy 1-1/8 - 1-1/2" Integrated

Fork Fox 34 Float Performance 140 QR15x110

Damper Fox Float DPS Performance 3-Position Evol custom tune 210x50mm

Saddle Fizik Taiga S-alloy rail

Bar OC2 Dropper 31,6 mm

Frame material Aluminium

Drive

Derailleurs 1x12

Number of gears 12

Rear derailleur (model) Shimano XT M8100 SGS Shadow Plus

Handles Shimano SLX M7100 I-Spec EV

Crank mechanism Race Face Aeffect 32t

Cassette / Freewheel Shimano CS-M7100 10-51t 12-Speed

Chain Shimano M6100

Brakes

Brakes (model) Shimano M6100 Hydraulic Disc

Brake type Hydraulic discs

Wheels

Wheel size 29"

Wheels Race Face AR 30c Tubeless Ready

Tyres Maxxis Dissector 2,40" 60 TPI 3CMaxxTerra Exo TLR, Maxxis Rekon 2.40" FB 60 TPI Dual Exo TR

Tubeless ready wheels Yes

Tubeless ready tyres Yes

Additional information

Lighting No

Mudguards No

Luggage carrier No

Folding condition of the bike Bike adjusted and pre-assembled

Other data

Sport Bicycles

Brand Orbea

Leading colour Green

Season Year-round

Model/product code Occam M30 M25615LT

Purpose MTB

Gender Male, Woman

Country of origin of the brand Spain

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.

Code 2000038708

Size	S	M	L	XL
Height (cm)	150-165	160-175	170-185	180-198
A - Seat tube (mm)	381	419	457	508
B - Horizontal pipe (mm)	565	592	619	649
C - Steerer tube (mm)	95	105	120	140
D - Rear triangle (mm)	440	440	440	440
E - Support height (mm)	336	336	336	336
F - Support lowering (mm)	35	35	35	35
G - Wheelbase (mm)	1165	1194	1224	1259
H - Head angle	66	66	66	66
I - Seat tube angle (°)	77	77	77	77
J - Crossover (mm)	710	736	766	776
K - Reach (mm)	425	450	474	500
L - Stack (mm)	604	613	627	646
M - Fork (mm)	547	547	547	547

Advantages

Carbon frame

When designing this bike, the focus was on selecting the right materials to ensure the highest quality. Therefore, the frame is made of carbon, which combines lightness and resilience in addition to effectively damping vibrations.

Hydraulic disc brakes

This mountain bike model uses hydraulic disc brakes, which have a very low failure rate, so they will be trouble-free even during frequent use. The undoubted advantage is greater braking power and modulation.

Tubeless ready tyres

The use of TLR (Tubeless Ready) technology has made it possible to use lower pressures and makes the tyres resistant to punctures. What's more, the system rules out the problem of ‘Snake Bite’, i.e. puncturing the inner tube by pinching it against the rim.

Full shock absorption

Allows easier traversing of off-road obstacles. Front and rear shock absorbers provide maximum wheel traction control and a balanced ride on the ground. The full suspension bike is very comfortable and soft to ride.

Drive 1x12

This bike uses 1x12 derailleurs, which provide smooth gradation and allow effortless gear changes. The large range of gear ratios allows you to adapt the gear to your current needs.

29" wheels

The use of 29 wheels has made it possible to provide more and better tyre contact with the ground, which makes it much easier to overcome bumps when riding over difficult terrain. This size guarantees good stability when riding at higher speeds.
