Frame
Frame of hydroformed aluminium
Frame material Aluminium
Components
Steering wheel Zoom MTB-AL-312BT
Handlebar material Aluminium
Handlebar support Promax MA-47 (31,8 mm x 90 mm)
Grips Velo VLG-776-12D3 + VLP-171
Depreciation Front
Fork RST BLAZE TNL 29 (stroke: 100 mm)
Saddle Velo VL-3363 NP1
Drive
Derailleurs 1x9
Number of gears 9
Rear derailleur (model) Shimano Alivio 9-speed
Handles Shimano Altus
Cassette / Freewheel Shimano HG200-9, 11-36T
Chain KMC X9
Brakes
Brakes (model) Shimano MT200
Brake type Hydraulic discs
Wheels
Wheel size 29"
Wheels Reinforced three-chamber wheels
Tyres Impac Smartpac 2.1
Hubs Shimano HB-TX505- front hub, Shimano HB-TX505- rear hub
spokes Sapim 13G / Front wheel: 290 mm / Rear wheel: 255 mm
Additional information
Support Yes
Lighting No
Mudguards No
Luggage carrier No
Maximum user weight 125 kg
Weight of bike (estimated) 24,5 kg
Folding condition of the bike Bike adjusted and pre-assembled
Warnings and producer's data
Producer 55-330 Źródła (koło Wrocławia), Polska | [email protected]
Other data
Sport Bicycles
Brand EcoBike
Leading colour Blue
Season Year-round
Model/product code SX300/14Ah X300 LG 1010405
Purpose MTB
Gender Male, Woman
Country of origin of the brand Poland
Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only., The maximum range of an e-bike is a conventional value, depending on factors such as weather, terrain and the weight of the user.
Code 2000032969
Engine model DAPU
Engine location Hub
Engine power 250 W
Maximum engine power 840 W
Maximum torque 95 Nm
Maximum speed 40 km/h ( assistance limited to 25 km/h in the settings)
Battery type Lithium-ion
Battery capacity 672 Wh
Battery location In the frame
Maximum range 130 km
Charger 100-240V / 54.6V / 3A / Type D
| Frame size | 18" | 20" |
| Height (cm) | 170-185 | 175-190 |
| A - Rura pozioma (mm) | 595,40 | 600 |
| B - Rura sterowa (mm) | 165 | 165 |
| C - Rura podsiodłowa (mm) | 457 | 508 |
| D - Wheel base (mm) | 1149,40 | 1149,40 |
| E - Kąt siodełka (°) |
73 | 73 |
| F - Kąt główki (°) | 68 | 68 |
Advantages
Front cushioning
The cushioning makes cycling over uneven ground much more pleasant and comfortable. This model is equipped with front suspension, which ensures safety and absorbs the force when the front wheel hits an obstacle.
Aluminium frame
The use of an aluminium frame in this model of bicycle makes it extremely light and strong, so that moving the bicycle from place to place is not a problem. In addition, this material is characterised by its resistance to deformation.
Long range
This e-bike model has been designed to guarantee the highest possible level of quality. That is why the bike has been equipped with an optimised battery that provides a long range and freedom to explore the terrain.
Hydraulic disc brakes
The given model of the bike is equipped with hydraulic disc brakes. This type has a very low failure rate, ensuring that the brakes will be trouble-free, even during frequent use. In addition, they feature greater braking power and modulation.
29" wheels
The use of 29’ wheels allows for greater and better tyre contact with the ground, making it much easier to overcome bumps when riding over rough terrain. This size guarantees good stability when riding at higher speeds.
MichałGood choice
This is my first electric, having previously used an analogue MTB for a dozen years. I'm now learning to ride off-road from scratch, but it's a pleasure (mainly the power steering and derailleur changes on climbs). The power steering works smoothly, you can dose your effort and spend more time on 2 wheels. The analogue engine-assist handlebar is very useful when homing in.
- Szymon
Robust equipment
No gear indicator in the handle
- Michał
revelation
Seemingly, this model does not stand out from the competition, but if you take into account a very powerful, very modern engine, a nicely designed and made frame, sensibly selected components without overly fat tyres as befits a recreational hardtail and enormous fun to ride, it is, in my opinion, the best choice up to £9999.
