Basic data
Sport Bicycles
Brand Orbea
Leading colour Red
Season Year-round
Model/product code VIBE H10 EQ M31049YH
Purpose City/urban
Gender Male, Woman
Country of origin of the brand Spain
Warnings The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only., The maximum range of an e-bike is a conventional value, depending on factors such as weather, terrain and the weight of the user.
Code 2000031667
Frame
Frame Orbea Vibe Top Bar Hydro 6061, ICR cable routing, Forged BB, 135x9 QR, 700x45 maximun tire, carrier and fenders compatible
Frame material Aluminium
Components
Steering wheel Alloy 31.8mm 12mm Rise 700mm
Handlebar support OC1 31.8mm interface -6º
Grips Brooks Comfort Cambium 130mm
Depreciation No
Rudders Acros Alloy 1-1/2" Internal Cable Routing
Fork Orbea Vibe carbon fork, full carbon, 1-1/5, 700x45 maximun tire, flat mount disc mount, Thrue Axle12x100mm
Saddle Brooks Cambium C15 283x140
Bar Alloy 27.2 Offset 20
Drive
Derailleurs 1x12
Number of gears 12
Rear derailleur (model) Shimano XT M8100 SGS Shadow Plus
Handles Shimano Deore M6100
Crank mechanism OC 42t, w/Chainguard
Cassette / Freewheel Sun Race CSMZ80 11-51t 12-Speed Metallic E-bike
Chain KMC X12
Brakes
Brakes (model) Magura MT5 E-STOP Hydraulic Disc Easy Route Connection
Brake type Hydraulic discs
Wheels
Wheel size 28"
Wheels Ready GR
Tyres Kenda K1052 700x45C Reflective type TLR
Hubs Orbea Thru Axle 12x100mm M12x2 P1 Hollow - front hub
Additional information
Support Ursus Mooi R90 rear alloy adjustable
Lighting Lezyne Ebike POWER STVZO PRO E115 310 lumens (front), Lezyne FENDER STVZO (rear)
Mudguards CURANA Apollo 55mm
Luggage carrier Orbea Vibe rear luggage carrier (max: 15 kg)
Maximum user weight 120 kg
Weight of bike (estimated) 21,2 kg
Folding condition of the bike Bike adjusted and pre-assembled
Care and environment
Standards, certificates CE
Warnings and producer's data
Producer Orbea S. Coop. | Polígono Industrial Goitondo, s/n, 48260 Mallabia, Bizkaia, Hiszpania | [email protected]
Other data
Engine model Ebikemotion X35 Plus 25kmh
Engine location Hub
Engine power 250 W
Battery type Lithium-ion
Battery capacity 248 Wh
Battery location In the frame
Maximum range 70 km
Charger Ebikemotion X35
Advantages
Aluminium frame
The use of an aluminium frame in this model of bicycle makes it extremely light and strong, so that moving the bicycle from place to place is not a problem. In addition, this material is characterised by its resistance to deformation.
Hydraulic disc brakes
The given model of the bike is equipped with hydraulic disc brakes. This type has a very low failure rate, ensuring that the brakes will be trouble-free, even during frequent use. In addition, they feature greater braking power and modulation.
28" wheels
The use of 28-inch wheels on this model has made the bike faster to reach higher speeds and much easier to maintain. This wheel size allows the bike to negotiate obstacles comfortably and provides better stability at higher speeds.
Drive 1x12
The 1x12 derailleurs used on this e-bike model guarantee smooth gradation and allow effortless gear changes. The large gear range allows you to adapt the gear to the current road conditions.
