Frame
Frame Series 3 Beyond Road, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Flat Mount Disc, 142x12mm Thru-Axle
Frame material Aluminium
Components
Steering wheel Marin Butted Alloy, Compact 16º Flared Drop
Handlebar support Marin 3D Forged Alloy
Grips Marin Shock Absorbing Perforated Tape
Rudders FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”
Fork Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
Fork material Carbon fibre
Saddle Marin Beyond Road Concept Elite
Bar TranzX YSP38J, Size S-M 70mm, Size L-XL 110mm Travel, 27.2mm
Drive
Type of derailleur Mechanical
Derailleurs 1x12
Number of gears 12
Rear derailleur (model) SRAM Apex 1
Handles Sram Apex 1x
Suport SRAM DUB BSA
Crank mechanism SRAM Apex 1, 40T
Cassette / Freewheel SRAM CS-XG-1275, 10-52T
Chain SRAM NX
Brakes
Brakes (model) SRAM Apex 1 Flat-Mount Hydraulic Disc
Brake type Hydraulic discs
Brake discs 160 mm front / 160 mm rear
Wheels
Wheel size 28"
Wheels Marin Aluminum Double Wall, 25mm Inner, 18mm Tall, Disc Specific, Tubeless Compatible
Tyres Vee Tire Co., Rocket Man, 700x44, Tubeless Compatible
Hubs Forged Aluminum Alloy, 142x12mm, Disc, 32H, Forged Aluminum Alloy, 100x12mm, Disc, 32H
spokes 14g Black Stainless Steel
Tubeless ready wheels Yes
Tubeless ready tyres Yes
Additional information
Pedals included No
Folding condition of the bike Bike adjusted and pre-assembled
Warnings and producer's data
Producer Petaluma, CA 94954, USA | [email protected]
Other data
Sport Bicycles
Brand Marin
Leading colour Black
Season Year-round
Model/product code Gestalt XR 700C A-2030W-X1-50
Gender Male, Woman
Country of origin of the brand USA
Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.
Code 2000104771
| Size | S | M | L | XL |
| Height (cm) | 160-168 | 168-178 | 178-188 | 188-193 |
| A - STACK | 547,6 | 566 | 589,1 | 621,5 |
| B - REACH | 400 | 420 | 440 | 460 |
| 67,5 | 67,5 | 67,5 | 67,5 | |
| D - Steering tube (mm) | 130 | 150 | 175 | 210 |
| E - Kąt siodełka (°) |
75 | 74 | 74 | 74 |
| 460 | 485 | 505 | 530 | |
| 546,7 | 582,3 | 608,9 | 638,2 | |
| 282,5 | 282,5 | 282,5 | 282,5 | |
| 80 | 80 | 80 | 80 | |
| 425 | 425 | 425 | 425 | |
| 1065,2 | 1092,8 | 1122,4 | 1155,6 | |
| 678,6 | 687,7 | 708,6 | 734,5 | |
| 50 | 50 | 50 | 50 |
