Frame
Frame material Aluminium
Components
Steering wheel Aluminium, 10° backsweep, 560 mm
Handlebar width 56 cm
Handlebar support Aluminium, 40 mm, +10°
Grips Rubber 120 mm
Depreciation No
Rudders 1"-1/8 Semi-Integrated
Fork material Aluminium
Bar 27.2 mm aluminium
Drive
Derailleurs 1x7
Number of gears 7
Rear derailleur (model) Shimano Altus, 7 speed
Handles SHIMANO SL-M315 Rapidfire
Crank mechanism Prowheel 32T 127mm
Cassette / Freewheel SHIMANO CS-HG200-7 (12-32T)
Chain KMC Z7
Brakes
Brakes (model) TEKTRO V-brake J310
Brake type Mechanical jaws
Wheels
Wheel size 20"
Wheels Aluminium, double chamber 24H 14G
Tyres Kenda K879 20 x 1.75"
Additional information
Pedals included Yes
Side wheels No
Maximum user weight 70 kg
Weight of bike (estimated) 9,1 kg
Other data
Sport Bicycles
Brand ATTABO
Leading colour Red
Season Year-round
Model/product code EASE 20" ATB-EAS201
Gender Boy, Girl
Country of origin of the brand Poland
Model colour 2000103122
Below you will find information that will help you choose the right size when buying a child's Ease 20 bike from ATTABO.
| Wheel size | 20 |
| Height (cm) | 115-135 |
| Maximum user weight (kg) | 70 |
| Age | 6-9 |
| A | 70 |
| B Height of handlebars (mm) | 760 |
| C Length of top tube measured horizontally (mm) | 439 |
| D Wheels base (mm) | 880 |
| E Seat tube angle (°) | 72 |
| F Section height (mm) | 460 |
| G Saddle height range (mm) | 620-740 |
| Crank arm length (mm) | 127 |
Advantages
Aluminium frame
The junior bike has been designed with attention to every element. Its frame is made of durable aluminium, which stands out for its low weight. In addition, this material is characterised by its strength and resistance to deformation.
V-brake type
This bike is equipped with reliable, universal V-Brake brakes, which are used on the vast majority of bikes, as they are extremely durable and easy to install and maintain.
