Superior XC 819 gloss dark red/silver mountain bike (801.2022.29085)

Frame

Frame Alu 6061 T6 Double Butted, Smooth Welding, Sport Geometry, Conical Head Tube

Frame material Aluminium

Components

Steering wheel ONE1 Alloy, MTB AL-312BT, 9° backsweep, 12mm rise, 740mm, 31.8mm

Handlebar support ONE1 Sport MAS-D61248 Alloy, 31.8mm, -8°

Grips ONE1 VLG-1661D2N, Lock-On

Depreciation Front

Rudders CHH1505 1-1/8“, ZS44/28.6 - ZS56/30

Fork RST Blaze, 1-1/8", 100mm travel

Saddle Selle Royal Vivo HRN

Bar ONE1 Sport Alloy, SP C207, 30.9mm

Drive

Derailleurs 2x8

Number of gears 16

Front derailleur (model) SHIMANO FD-M315-TS, TOP SWING, DUAL-PULL

Rear derailleur (model) SHIMANO ALTUS RD-M310-L

Handles SHIMANO ALTUS SL-M315-2L RapidFire Plus, 2-speed, SHIMANO ALTUS SL-M315-8R RapidFire Plus, 8-speed

Crank mechanism SHIMANO FC-M315, 36-22T

Cassette / Freewheel SHIMANO CS-HG31-8, 11-34T

Chain KMC Z8.3

Brakes

Brakes (model) SHIMANO BL-MT200/BR-MT200

Brake type Hydraulic discs

Wheels

Wheel size 29"

Wheels Stars J25DH, 32H

Tyres Schwalbe Smart Sam, 29x2.10"

Hubs SHIMANO HB-TX505, 32H, CENTER LOCK, QR Type, SHIMANO FH-TX505-8, 32H, CENTER LOCK, M10x135mm, QR Type

spokes Sapim Galvanized Black

Additional information

Pedals included Yes

Folding condition of the bike Bike adjusted and pre-assembled

Other data

Sport Bicycles

Brand Superior

Leading colour Red

Season Year-round

Model/product code XC 819 801.2022.29085

Gender Male, Woman

Country of origin of the brand European Union

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.

Model colour 2000089650

Below you will find information that will help you choose the right size when buying an XC 819 bike from Superior.

Size	16" (S)	18" (M)	20" (L)	22" (XL)
Height (cm)	160-170	171-180	181-190	191-200
A - Seat tube (mm)	406	457	508	559
B - Horizontal pipe (mm)	570	590	610	630
C - Kąt siodełka (°)	74	74	74	74
D - Head angle (°)	69	69	69	69
E - Rear triangle (mm)	442	442	442	442
F - Wheel base (mm)	1096	1119	1139	1160
G - Rura sterowa (mm)	100	120	120	140
R - Reach (mm)	393	408	428	443
S - Stack (mm)	615	634	634	653

Advantages

Front cushioning

The cushioning on the bike provides comfort when negotiating bumps in the road. This model features front wheel cushioning, which absorbs the force when hitting an obstacle and increases the level of safety.

Aluminium frame

The aluminium frame is characterised by its high resistance to scratches and damage. In addition, this material is characterised by its low weight, which makes carrying the bike no problem.

Hydraulic disc brakes

This mountain bike is equipped with hydraulic disc brakes, which have a very low failure rate so that use will be trouble-free, even during frequent use. In addition, they feature greater braking power and modulation.

29" wheels

The use of 29 wheels has made it possible to provide more and better tyre contact with the ground, which makes it much easier to overcome bumps when riding over rough terrain. This size guarantees good stability when riding at higher speeds.
