Orbea Rise M20 42V 360Wh 2023 chameleon goblin green/black electric bike (N37407V1)

Frame

Frame Orbea Rise Evo OMR 2023, 140mm travel, 29" wheels, Concentric Boost 12x148

Frame material Carbon fibre

Components

Steering wheel OC Mountain Control MC21 Alu SL, Rise20, Width 800

Handlebar width 800 mm

Handlebar material Aluminium

Handlebar support OC Mountain Control MC20, 0º

Handlebar stem material Aluminium

Depreciation Full

Fork Fox 34 Float Performance 140 3-Position QR15x110

Damper Fox Float DPS Performance 3-Position Evol custom tune 210x55mm

Saddle Fizik Taiga S-alloy rail

Bar OC Mountain Control MC20, 31.6mm, Dropper

Drive

Rear derailleur (model) Shimano SLX M7100 SGS Shadow Plus

Handles Shimano SLX M7100 I-Spec EV

Crank mechanism Shimano Steps EM600

Cassette / Freewheel Shimano CS-M7100 10-51t 12-Speed

Chain Shimano M6100

Brakes

Brakes (model) Shimano M6100 Hydraulic Disc

Brake type Hydraulic discs

Wheels

Wheel size 29"

Wheels Race Face AR 30c Tubeless Ready

Tyres TYRES Maxxis Dissector 2.40" 60 TPI 3CMaxxTerra Exo TLR

Additional information

Folding condition of the bike Bike adjusted and pre-assembled

Other data

Sport Bicycles

Brand Orbea

Leading colour Green

Season Year-round

Model/product code Rise M20 N37407V1

Purpose MTB

Gender Male, Woman

Country of origin of the brand Spain

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only., The maximum range of an e-bike is a conventional value, depending on factors such as weather, terrain and the weight of the user.

Model colour 2000066967

Engine model Shimano EP8

Engine location Central

Engine power 250 W

Battery capacity 360 Wh

Battery location In the frame

Size	S	M	L	XL
Height (cm)	150-165	160-175	170-185	180-198
A - Seat tube (mm)	381	419	457	508
B - Horizontal pipe (mm)	565	592	619	649
C - Steerer tube (mm)	95	105	120	140
D - Rear triangle (mm)	445	445	445	445
E - Support height (mm)	336	336	336	336
F - Support lowering (mm)	35/32	35/32	35/32	35/32
G - Wheelbase (mm)	1180	1205	1229	1255
H - Head angle	66/65,5	66/65,5	66/65,5	66/65,5
I - Seat tube angle (°)	77/76,5	77/76,5	77/76,5	77/76,5
J - Crossover (mm)	710	736	766	776
K - Reach (mm)	425	450	474	500
L - Stack (mm)	604	613	627	646
M - Fork (mm)	547	547	547	547

Advantages

Carbon frame

The use of a carbon frame on this model of bike makes it extremely light and resilient, making use much more comfortable. In addition, the carbon frame effectively dampens vibrations when negotiating bumps.

Hydraulic disc brakes

The given model of the bike is equipped with hydraulic disc brakes. This type has a very low failure rate, ensuring that the brakes will be trouble-free, even during frequent use. In addition, they feature greater braking power and modulation.

Tubeless ready tyres

Thanks to the use of Tubeless Ready (TLR) technology, the tyres are resistant to punctures and lower pressures can be applied. Furthermore, the system eliminates the problem of ‘Snake Bite’, i.e. puncturing the inner tube by pinching against the rim.

Full shock absorption

Full suspension, i.e. both the front and rear wheels, allows you to negotiate obstacles in difficult terrain more comfortably. A bike with full suspension provides more grip and efficiency.

Drive 1x12

The 1x12 derailleurs used on this e-bike model guarantee smooth gradation and allow effortless gear changes. The large gear range allows you to adapt the gear to the current road conditions.

29" wheels

The use of 29’ wheels allows for greater and better tyre contact with the ground, making it much easier to overcome bumps when riding over rough terrain. This size guarantees good stability when riding at higher speeds.
