LOVELEC electric bicycle Sargo 20Ah pink/black B400342

Parameters

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only., The maximum range of an e-bike is a conventional value, depending on factors such as weather, terrain and the weight of the user.

Model/product code Sargo 20Ah B400342

Leading colour Pink

Brand LOVELEC

Country of origin of the brand European Union

Gender Male, Woman

Season Year-round

Engine location Central

Engine power 250 W

Crank mechanism Prowheel, 175 mm

Wheel size 29"

Sport Bicycles

Derailleurs 1x9

Cassette / Freewheel SunRace CSM909 11-34T

Rear derailleur (model) Shimano Alivio 9-speed

Handles Shimano Alivio

Depreciation Front

Battery location In the frame

Brakes (model) Tektro HD-T275

Purpose MTB

Maximum range 170 km

Chain KMC

Handlebar support Promax

Tyres Kenda K1227, 29×2.4

Lighting No

Frame material Aluminium

Fork SunTour XCM

Engine model DAPU

Saddle Selle Royal

Steering wheel Promax, 720 mm

Weight of bike (estimated) 25 kg

Maximum engine power 750 W

Brake type Hydraulic discs

Number of gears 9

Battery capacity 720 Wh

Folding condition of the bike Bike adjusted and pre-assembled

Hubs Modus - front hub, Modus - rear hub

Maximum torque 95 Nm

Battery type Lithium-ion

Support Yes

spokes Steel

Mudguards No

Luggage carrier No

LOVELEC electric bicycle Sargo 20Ah pink/black B400342 2

Sizes table

Size	17"	19"	20,5"
Height (cm)	160-175	175-188	185-195
A - angle of the head tube	67	67	67
B - seat tube angle (mm)	72	72	72
C - effective top tube length (mm)	605	620,9	635
D - top tube length (mm)	578,2	590,5	604,4
E - seat tube length (mm)	430	480	520
F - rear triangle length (mm)	480	480	480
G wheels base (mm)	1166,7	1182,6	1198,6
H - head tube height (mm)	130	130	150

Product description

Advantages

Front cushioning

The cushioning makes cycling over uneven ground much more pleasant and comfortable. This model is equipped with front suspension, which ensures safety and absorbs the force when the front wheel hits an obstacle.

Aluminium frame

The use of an aluminium frame in this model of bicycle makes it extremely light and strong, so that moving the bicycle from place to place is not a problem. In addition, this material is characterised by its resistance to deformation.

Hydraulic disc brakes

The given model of the bike is equipped with hydraulic disc brakes. This type has a very low failure rate, ensuring that the brakes will be trouble-free, even during frequent use. In addition, they feature greater braking power and modulation.

29" wheels

The use of 29’ wheels allows for greater and better tyre contact with the ground, making it much easier to overcome bumps when riding over rough terrain. This size guarantees good stability when riding at higher speeds.
