Frame
Frame Orbea Oiz Hydro High Polished, Alloy link, Boost, BSA, SIC, UFO, I-Line shock
Frame material Aluminium
Components
Steering wheel Alloy, 31.8mm, Flat, 740mm, Sweep 9
Handlebar support OC Mountain Performance MP21, -6º
Grips OC Lock On
Depreciation Full
Rudders FSA 1-1/2" Integrated Aluminium Cup
Fork Fox 32 Float Rhythm 120 Remote Push to Lock QR15x110
Damper Fox Float SL Performance 120mm Remote Push-lock Evol custom tune190x45mm
Saddle Selle Italia Model X FecAlloy Rail 145x248mm
Bar OC Mountain Control MC21, 31.6mm, Dropper
Drive
Derailleurs 1x12
Number of gears 12
Rear derailleur (model) SRAM GX Eagle Lunar
Handles SRAM GX Eagle Lunar
Crank mechanism SRAM Stylo 6K Eagle Dub Boost 32t Steel
Cassette / Freewheel SRAM PG-1230 Eagle 11-50t 12-Speed
Chain SRAM NX Eagle 12-Speed
Brakes
Brakes (model) Shimano M6100 Hydraulic Disc
Brake type Hydraulic discs
Wheels
Wheel size 29"
Wheels Alloy, Tubeless, 25c, 32H
Tyres Maxxis Rekon Race 2.40" WT 120 TPI Exo TLR
Additional information
Folding condition of the bike Bike adjusted and pre-assembled
Other data
Sport Bicycles
Brand Orbea
Leading colour White
Season Year-round
Model/product code Oiz H20 R23109N5
Gender Male, Woman
Country of origin of the brand Spain
Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.
Code 2000103861
| Size | S | M | L | XL |
| Height (cm) | 155-170 | 165-180 | 178-190 | 185-198 |
| A - Seat tube (mm) | 410 | 432 | 460 | 510 |
| B - Horizontal pipe (mm) | 568 | 594 | 619 | 645 |
| C - Steerer tube (mm) | 90 | 95 | 105 | 115 |
| D - Rear triangle (mm) | 436 | 436 | 436 | 436 |
| E - Support height (mm) | 333 | 333 | 333 | 333 |
| F - Support lowering (mm) | 42 | 42 | 42 | 42 |
| G - Wheelbase (mm) | 1142 | 1169 | 1195 | 1223 |
| H - Head angle | 67 | 67 | 67 | 67 |
| I - Seat tube angle (°) | 76,5 | 76,5 | 76,5 | 76,5 |
| J - Crossover (mm) | 729 | 743 | 746 | 743 |
| K - Reach (mm) | 425 | 450 | 472 | 496 |
| L - Stack (mm) | 596 | 600 | 610 | 619 |
| M - Fork (mm) | 531 | 531 | 531 | 531 |
Advantages
Aluminium frame
When designing this bike, the focus was on selecting the right materials to ensure the highest quality. Therefore, the frame is made of aluminium, which combines durability and low weight.
Hydraulic disc brakes
This mountain bike model uses hydraulic disc brakes, which have a very low failure rate, so they will be trouble-free even during frequent use. The undoubted advantage is greater braking power and modulation.
Full shock absorption
Allows easier traversing of off-road obstacles. Front and rear shock absorbers provide maximum wheel traction control and a balanced ride on the ground. The full suspension bike is very comfortable and soft to ride.
Drive 1x12
This bike uses 1x12 derailleurs, which provide smooth gradation and allow effortless gear changes. The large range of gear ratios allows you to adapt the gear to your current needs.
29" wheels
The use of 29 wheels has made it possible to provide more and better tyre contact with the ground, which makes it much easier to overcome bumps when riding over difficult terrain. This size guarantees good stability when riding at higher speeds.
