Orbea Oiz H30 2024 white chic/shadow coral mountain bicycle (R23003N5)

Frame

Frame Orbea Oiz Hydro High Polished, Alloy link, Boost, BSA, SIC, UFO, I-Line shock

Frame material Aluminium

Components

Steering wheel Alloy, 31.8mm, Flat, 740mm, Sweep 9

Handlebar support OC Mountain Performance MP21, -6º

Grips OC Lock On

Depreciation Full

Rudders FSA 1-1/2" Integrated Aluminium Cup

Fork Fox 32 Float Rhythm 120 Remote Push to Lock QR15x110

Damper Fox Float SL Performance 120mm Remote Push-lock Evol custom tune190x45mm

Saddle Fortune QF-3091

Bar Alloy, 31.6mm, Setback 0

Drive

Derailleurs 1x12

Number of gears 12

Rear derailleur (model) Shimano Deore M6100 SGS Shadow Plus

Handles Shimano Deore M6100

Crank mechanism Forged alloy, 32t, Boost

Cassette / Freewheel Sun Race 11-51t 12-Speed

Chain KMC X12

Brakes

Brakes (model) Shimano MT201 Hydraulic Disc

Brake type Hydraulic discs

Wheels

Wheel size 29"

Wheels Alloy, Tubeless, 25c, 32H

Tubeless ready wheels Yes

Additional information

Folding condition of the bike Bike adjusted and pre-assembled

Other data

Sport Bicycles

Brand Orbea

Leading colour White

Season Year-round

Model/product code Oiz H30 R23003N5

Gender Male, Woman

Country of origin of the brand Spain

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.

Code 2000097375

Size	S	M	L	XL
Height (cm)	155-170	165-180	178-190	185-198
A - Seat tube (mm)	410	432	460	510
B - Horizontal pipe (mm)	568	594	619	645
C - Steerer tube (mm)	90	95	105	115
D - Rear triangle (mm)	436	436	436	436
E - Support height (mm)	333	333	333	333
F - Support lowering (mm)	42	42	42	42
G - Wheelbase (mm)	1142	1169	1195	1223
H - Head angle	67	67	67	67
I - Seat tube angle (°)	76,5	76,5	76,5	76,5
J - Crossover (mm)	729	743	746	743
K - Reach (mm)	425	450	472	496
L - Stack (mm)	596	600	610	619
M - Fork (mm)	531	531	531	531

Advantages

Aluminium frame

When designing this bike, the focus was on selecting the right materials to ensure the highest quality. Therefore, the frame is made of aluminium, which combines durability and low weight.

Hydraulic disc brakes

This mountain bike model uses hydraulic disc brakes, which have a very low failure rate, so they will be trouble-free even during frequent use. The undoubted advantage is greater braking power and modulation.

Full shock absorption

Allows easier traversing of off-road obstacles. Front and rear shock absorbers provide maximum wheel traction control and a balanced ride on the ground. The full suspension bike is very comfortable and soft to ride.

Drive 1x12

This bike uses 1x12 derailleurs, which provide smooth gradation and allow effortless gear changes. The large range of gear ratios allows you to adapt the gear to your current needs.

29" wheels

The use of 29 wheels has made it possible to provide more and better tyre contact with the ground, which makes it much easier to overcome bumps when riding over difficult terrain. This size guarantees good stability when riding at higher speeds.
