Haibicycle Lyke CF 11 430 Wh electric bicycle royal/red/tuscan matt (45812440)

Frame

Frame Haibike carbon, 29", 140mm

Frame material Carbon fibre

Components

Steering wheel XLC FlowBy, 780 mm

Handlebar width 780 mm

Handlebar support XLC FlowBy, A-head, Handlebar diameter: 31.8 mm

Depreciation Full

Rudders Acros BlockLock

Fork FOX 36 Float Performance, air, 140mm

Damper FOX Float DPS Performance EVOL, air

Saddle Selle Italia Model X

Bar dropper-post remote, telescope, 31.6 mm, aluminium

Frame material Aluminium

Drive

Type of derailleur Mechanical

Derailleurs 1x12

Number of gears 12

Handles Deore XT M8100

Crank mechanism Rotor E-Kapic

Cassette / Freewheel Shimano M7100

Chain Shimano SLX M7100

Brakes

Brakes (model) Shimano Deore XT M8120, 203mm / 180mm

Brake type Hydraulic discs

Wheels

Wheel size 29"

Wheels Mavic E- Crossmax XL S

Tyres Maxxis Dissector MaxxTerra EXO+, 62-622

Additional information

Maximum user weight 120 kg

Folding condition of the bike Bike adjusted and pre-assembled

Warnings and producer's data

Producer 57076 Siegen, Niemcy | [email protected]

Other data

Sport Bicycles

Brand Haibike

Leading colour Maroon

Season Year-round

Model/product code Lyke CF 11 45812440

Purpose MTB

Gender Male, Woman

Country of origin of the brand Germany

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only., The maximum range of an e-bike is a conventional value, depending on factors such as weather, terrain and the weight of the user.

Code 2000097898

Engine model Fazua Ride60

Engine location Central

Engine power 250 W

Maximum torque 60 Nm

Maximum speed 25 km/h

Battery capacity 430 Wh

Below you will find information that will help you choose the right size when buying a Lyke CF 11 electric bike from Haibike.

Size	M/44	L/47
Height (cm)	168-176	176-184
A (mm)	440	470
B	74°	74°
C (mm)	36	36
D	77,3°	77,3°
E (mm)	120	130
F	65°	65°
G (mm)	592	622
H (mm)	450	450
I (mm)	-25	-25
J (mm)	1227	1259
K (mm)	382	389
L (mm)	548	570

Advantages

Carbon frame

The use of a carbon frame on this model of bike makes it extremely light and resilient, making use much more comfortable. In addition, the carbon frame effectively dampens vibrations when negotiating bumps.

Hydraulic disc brakes

The given model of the bike is equipped with hydraulic disc brakes. This type has a very low failure rate, ensuring that the brakes will be trouble-free, even during frequent use. In addition, they feature greater braking power and modulation.

Full shock absorption

Full suspension, i.e. both the front and rear wheels, allows you to negotiate obstacles in difficult terrain more comfortably. A bike with full suspension provides more grip and efficiency.

Drive 1x12

The 1x12 derailleurs used on this e-bike model guarantee smooth gradation and allow effortless gear changes. The large gear range allows you to adapt the gear to the current road conditions.

29" wheels

The use of 29’ wheels allows for greater and better tyre contact with the ground, making it much easier to overcome bumps when riding over rough terrain. This size guarantees good stability when riding at higher speeds.
