-€706.00
Kellys Tygon R50 P 29" 36V 20Ah 725Wh steel blue electric bike
Code #2000073712
- We are calculating the delivery time for you More
- Free delivery over 125 € More
- 30 days to return More
Immediate shipment in 24 hours direct to you.
More about the shipmentBrowse similar products:
Parameters
Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only., The maximum range of an e-bike is a conventional value, depending on factors such as weather, terrain and the weight of the user.
Model/product code Tygon R50 P 29" 725Wh 76129
Leading colour Blue
Brand Kellys
Country of origin of the brand European Union
Gender Male, Woman
Season Year-round
Engine location Central
Engine power 250 W
Crank mechanism SAMOX (34T) - length 170 mm
Wheel size 29"
Frame KELLYS TYGON R-series
Sport Bicycles
Derailleurs 1x10
Cassette / Freewheel SHIMANO CS-M4100-10 (11-46T)
Rear derailleur (model) SHIMANO Deore M5120 (direct mount)
Handles SHIMANO Deore SL-M4100-R Rapidfire Plus (I-Spec EV)
Depreciation Front
Brakes (model) Shimano MT200 Hydraulic Disc
Purpose MTB
Brake discs 180 mm / 180 mm
Chain KMC e10T
Handlebar support KLS Active - diam 28.6 mm / bar bore 31.8 mm / 6° / length 80 mm
Bar KLS Active - diam 30.9 mm / length 350 mm
Tyres SCHWALBE Nobby Nic Performance 60-622 (29x2.35) ADDIX
Frame material Aluminium
Fork SR SUNTOUR Raidon 34 LOR DS (29") Boost, 120 mm, air / 15 mm thru axle
Pedals included Yes
Engine model PANASONIC GX Ultimate
Saddle Selle Royal Vivo
Steering wheel KLS Active RiseBar - diam 31.8 mm / rise 18 mm / width 720 mm
Brake type Hydraulic discs
Number of gears 10
Wheels KLS Valor 3 Disc 622x30 (32 holes)
Battery capacity 720 Wh
Folding condition of the bike Bike adjusted and pre-assembled
Hubs SHIMANO MT400-B Disc Center Lock (15x110 mm / 12x148 mm / 32 holes)
Maximum torque 95 Nm
Battery type Lithium-ion
Axle type 110 x 15 mm, 181 x 12 mm
Rudders FSA 1.5 semi-integrated
Sizes table
| Size | M | L | XL |
| Height (cm) | 169-180 | 178-189 | 186-197 |
| S/T (mm) | 440 | 490 | 520 |
| L (mm) | 627 | 652 | 672 |
| Reach (mm) | 440 | 465 | 485 |
| Stack (mm) | 653 | 653 | 653 |
| H/T (mm) | 140 | 140 | 140 |
| S/T (°) | 74 | 74 | 74 |
| H/T (°) | 67 | 67 | 67 |
| BB (mm) | 55 | 55 | 55 |
| RC (mm) | 455 | 455 | 455 |
| WB (mm) | 1204 | 1229 | 1249 |
