Orbea Orca M21e LTD PWR 2023 anthracite/black road bike (N74953BR)

Frame

Frame Orbea Orca carbon OMX Disc, monocoque construction, HS 1,5", BB 386mm, powermeter compatible

Frame material Carbon fibre

Components

Steering wheel OC Road Performance RP10 Carbon, Reach 80, Drop 125

Handlebar material Carbon fibre

Handlebar support OC Road Performance RP10, -8º

Fork Orbea Orca OMX ICR fork 2020, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1

Fork material Carbon fibre

Saddle Selle Italia SLR Boost SuperFlow L Carbon Rail Ø7x9 mm

Bar OC RP10 Road Performance, SB0/25, w/Micro tilt adj

Drive

Type of derailleur Electronic

Derailleurs 2x12

Number of gears 24

Front derailleur (model) SRAM Force eTAP AXS

Rear derailleur (model) SRAM Force AXS 12s

Handles SRAM Force AXS

Crank mechanism SRAM Force AXS Powermeter Dub 35x48t

Cassette / Freewheel SRAM XG-1270 10-33t 12-Speed

Brakes

Brakes (model) SRAM Force AXS

Brake type Hydraulic discs

Wheels

Wheel size 28"

Wheels Vision 40 SC Disc Carbon TLR CL

Tyres Vittoria Rubino Pro IV G2.0 700x25c

Hubs Orbea Thru Axle 12x100mm M12x2 P1 Lite - front hub, Orbea Thru Axle 12x142mm M12x2 P1 Lite - rear hub

Additional information

Folding condition of the bike Bike adjusted and pre-assembled

Other data

Sport Bicycles

Brand Orbea

Leading colour Grey

Season Year-round

Model/product code Orca M21e LTD PWR N74953BR

Gender Male, Woman

Country of origin of the brand Spain

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.

Type of Product Endurance

Code 2000066952

Size	53
Height (cm)	173-179
A - Seat tube (mm)	500
B - Horizontal pipe (mm)	548
C - Steerer tube (mm)	147,9
D - Rear triangle (mm)	-
E - Support height (mm)	269
F - Support lowering (mm)	70
G - Wheelbase (mm)	981
H - Head angle	72,8
I - Seat tube angle (°)	73,5
J - Crossover (mm)	780
K - Reach (mm)	385
L - Stack (mm)	552
M - Fork (mm)	-

Advantages

Carbon frame

The frame of this road bike has been made from extremely lightweight carbon, so carrying the bike is not a problem. Carbon is distinguished by the fact that it is very effective in reducing the force of vibrations generated when riding over rough terrain.

Hydraulic disc brakes

This road bike is equipped with hydraulic disc brakes, which have an extremely low failure rate, ensuring trouble-free use, even during frequent use. In addition, they are distinguished by their greater braking power and modulation.

28" wheels

The use of 28-inch wheels on this model has made the bike faster to reach higher speeds and much easier to maintain. This wheel size allows the bike to negotiate obstacles comfortably and provides better stability at higher speeds.

Electronic derailleurs

This model uses the state-of-the-art solution of electronic derailleurs, which are characterised by high quality and precision. This type allows instant gear changes.

Carbon fork

The fork on this bike is made of carbon, which is characterised by its extreme lightness and ability to absorb the power generated when riding over rough terrain. This material combines strength and low weight.
