Basic data
Sport Bicycles
Brand Orbea
Leading colour Blue
Season Year-round
Model/product code Gain D50 N31855D2
Purpose Road
Gender Male, Woman
Country of origin of the brand Spain
Code 2000066819
Frame
Frame Orbea Gain Hydro 6061 Hydroform Aluminum 2021, ICR cable routing
Frame material Aluminium
Components
Steering wheel OC Road Performance RP30, Reach 80, Drop 125
Handlebar material Aluminium
Handlebar support OC Road Performance RP21, -6º
Handlebar stem material Aluminium
Depreciation No
Fork Gain Hydro carbon fork, full carbon, 1-1/8" - 1.5" tappered head tube compatible
Fork material Carbon fibre
Saddle Fizik Aliante R5
Bar OC 27.2 Offset 0, for integrated light
Drive
Type of derailleur Mechanical
Derailleurs 2x8
Number of gears 16
Front derailleur (model) Shimano Claris FD-R2000-F
Rear derailleur (model) Shimano Claris RD-R2000-GS
Handles Shimano Claris ST-R2000
Crank mechanism Shimano Claris R2000 34x50t
Cassette / Freewheel Shimano HG50 11-32t 8-Speed
Chain KMC X8
Brakes
Brakes (model) Shimano BR-RS305
Brake type Mechanical discs
Wheels
Wheel size 28"
Wheels Orbea OC1
Tyres Hutchinson Fusion 5 Performance TLR 700x30
Hubs Orbea Thru Axle 12x100mm M12x2 P1 Hollow - front hub
Engine
Engine model Mahle motor hub X35 Plus 25kmh ( brushless )
Engine location Hub
Engine power 250 W
Maximum torque 40 Nm
Battery
Battery capacity 248 Wh
Battery location In the frame
Warnings and producer's data
Standards, certificates CE
Warnings The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only., The maximum range of an e-bike is a conventional value, depending on factors such as weather, terrain and the weight of the user.
Producer Orbea S. Coop. | Polígono Industrial Goitondo, s/n, 48260 Mallabia, Bizkaia, Hiszpania | [email protected]
Other data
Service label Bike assembly service available
Orbea Gain D50 36V 248Wh 2023 borealis blue/black electric bike (N31855D2)
Advantages
Aluminium frame
The use of an aluminium frame in this model of bicycle makes it extremely light and strong, so that moving the bicycle from place to place is not a problem. In addition, this material is characterised by its resistance to deformation.
28" wheels
The use of 28-inch wheels on this model has made the bike faster to reach higher speeds and much easier to maintain. This wheel size allows the bike to negotiate obstacles comfortably and provides better stability at higher speeds.
Mechanical disc brakes
A given model of bicycle is equipped with mechanical disc brakes. This type is characterised by high braking power and very low failure rate. Their simple design guarantees ease of possible repair.
