Orbea Wild H30 2023 is an exceptional electric bike that combines power, comfort, and durability, perfect for the most demanding cyclists.

Basic data

Brand Orbea
Country of origin of the brand Spain
Sport Bicycles
Gender Male, Woman
Season Year-round
Leading colour Grey
Model/product code Wild H30 N35905V8
Purpose MTB
Code 2000066795

Frame

Frame Orbea Wild Full Suspension Hydroformed Alloy 160mm Travel Boost 12x148 Bosch Gen4
Frame material Aluminium

Components

Steering wheel OC Mountain Control MC30, Rise20, Width 800
Handlebar width 800 mm
Handlebar material Aluminium
Handlebar support OC Mountain Control MC20, 0º
Handlebar stem material Aluminium
Depreciation Full
Fork RockShox 35 Silver TK Crown adjust Q15x110 Solo Air 160mm
Damper Fox Float DPS Performance Trunnion 3-Position Evol LV custom tune 205x65mm
Saddle Selle Royal Vivo 145x269mm
Bar OC Mountail Control MC20, 31.6mm, Dropper

Drive

Type of derailleur Mechanical
Derailleurs 1x12
Number of gears 12
Rear derailleur (model) Shimano XT M8100 SGS Shadow Plus
Handles Shimano Deore M6100
Crank mechanism E*Thirteen Plus Alu
Cassette / Freewheel Shimano CS-M6100 10-51t 12-Speed
Chain Shimano M6100

Brakes

Brakes (model) Shimano MT410 Hydraulic Disc
Brake type Hydraulic discs

Wheels

Wheel size 29"
Wheels Race Face AR 30c Tubeless Ready
Tyres Maxxis Minion DHF 2.60" 120 TPI FB 3C Maxx Terra Exo+ TR

Engine

Engine model BOSCH Performance Line CX
Engine location Central
Engine power 250 W
Maximum torque 85 Nm

Battery

Battery capacity 625 Wh
Battery location In the frame

Additional information

Pedals included No

Warnings and producer's data

Standards, certificates CE
Warnings The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only., The maximum range of an e-bike is a conventional value, depending on factors such as weather, terrain and the weight of the user.
Producer Orbea S. Coop. | Polígono Industrial Goitondo, s/n, 48260 Mallabia, Bizkaia, Hiszpania | info@orbea.com

Orbea Wild H30 625Wh 2023 basalt grey/dark teal electric bike (N35905V8)

Orbea Wild H30 2023 is a true powerhouse among electric bikes, packed with advanced technologies and a passion for exploring new trails. This exceptional machine is prepared for the most wild and demanding routes, while providing smoothness and full control during the ride.

BOSCH Performance Line CX motor with a power of 250 W and a torque of 85 Nm is the heart of the Orbea Wild H30. This highly efficient unit provides excellent support on steep climbs and long distances. Dynamic acceleration and quiet motor operation form a perfect combination that allows you to focus solely on the ride.

The battery with a capacity of 625 Wh is placed in the frame of the bike, which further enhances its aerodynamics and protects the battery from external factors. Thanks to such a large capacity, the bike enables long rides without the need for frequent charging.

Orbea Wild Full Suspension Hydroformed Alloy frame with 160 mm travel and Boost 12x148 standard was specially designed for bikes with Bosch Gen4 drive. It features full suspension, which guarantees excellent traction and riding comfort even on the toughest trails.

Orbea Wild H30 625Wh 2023 basalt grey/dark teal electric bike
UVEX bike helmet Viva 3 black S4109840115
Size
52-57 cm
56-62 cm
Choose an Option...

Choose an Option

  • 52-57 cm Notify me
  • 56-62 cm €66.99 €47.99
Add to Wish List
CamelBak Podium Chill bicycle bottle 710 ml black
Size
710 ml
Choose an Option...

Choose an Option

  • 710 ml €19.99 €17.99
Add to Wish List
Elite bicycle kit Custom Race Plus basket + Elite Fly Tex Maillot Jaune 550 ml bottle black
Size
550 ml
Choose an Option...

Choose an Option

  • 550 ml €23.99
Add to Wish List
Bike stand Orbea Onna/MX black
Size
27.5"-29"
Choose an Option...

Choose an Option

  • 27.5"-29" €42.99 €38.99
Add to Wish List
Feedback

There are no reviews yet, be the first!

Review this product

Orbea Wild H30 625Wh 2023 basalt grey/dark teal electric bike

Orbea Wild H30 625Wh 2023 basalt grey/dark teal electric bike

Overall rating
Please enter the order number under which you purchased this product at Sportano.

Orbea Wild H30 625Wh 2023 basalt grey/dark teal electric bike

No opinion

Bike assembly service available

Size M Sizes table
Choose an Option...

Choose an Option

Sizes table

    Size S M L XL
    Height (cm) 150-175 160-185 170-195 180-104
    A - Seat tube (mm) 415 415 435 460
    B - Horizontal pipe (mm) 573 595 622 649
    C - Steerer tube (mm) 110 120 130 140
    D - Rear triangle (mm) 448 448 448 448
    E - Support height (mm) 353 353 353 353
    F - Support lowering (mm) 25 25 25 25
    G - Wheelbase (mm) 1223 1247 1277 1306
    H - Head angle 64 64 64 64
    I - Seat tube angle (°) 77,5 77,5 77,5 77,5
    J - Crossover (mm) 700 700 700 700
    K - Reach (mm) 435 455 480 505
    L - Stack (mm) 621 630 639 648
    M - Fork (mm) 575 575 575 575
