Orbea Occam H10 2023 orange/black mountain bike

No opinion

We are calculating the delivery time for you More
Delivery from 3,99 € More
Bulky parcel More
30 days to return More

Frame

Frame Orbea Occam Hydro High Polished Triple Butted. Concentric Boost 12x148 rear axle. Pure Trail geometry. Internal cable routing

Frame material Aluminium

Components

Steering wheel OC Mountain Control MC30, Rise20, Width 800

Handlebar support OC1 3D Forged 35mm interface 7º

Depreciation Full

Fork Fox 34 Float Performance 140 3-Position QR15x110

Damper Fox Float DPS Performance 3-Position Evol custom tune 210x50mm

Saddle Fizik Taiga S-alloy rail

Bar OC Mountail Control MC20, 31.6mm, Dropper

Drive

Derailleurs 1x12

Number of gears 12

Rear derailleur (model) Shimano XT M8100 SGS Shadow Plus

Handles Shimano XT M8100 I-Spec EV

Crank mechanism Shimano XT M8100 32t

Cassette / Freewheel Shimano CS-M7100 10-51t 12-Speed

Chain Shimano M6100

Brakes

Brakes (model) Shimano XT M8100 Hydraulic Disc

Brake type Hydraulic discs

Wheels

Wheel size 29"

Wheels Race Face AR 30c Tubeless Ready

Tyres TYRES Maxxis Dissector 2.40" 60 TPI 3CMaxxTerra Exo TLR

Additional information

Folding condition of the bike Bike adjusted and pre-assembled

Other data

Sport Bicycles

Brand Orbea

Leading colour Orange

Season Year-round

Model/product code Occam H10 N25718LN

Gender Male, Woman

Country of origin of the brand Spain

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.

Code 2000066732

Sizes table

Below you will find information that will help you choose the right size when buying an Occam H10 bike from Orbea.

Size	M	L	XL
Height (cm)	160-175	170-185	180-198
A - Seat tube (mm)	419	457	508
B - Horizontal pipe (mm)	592	619	649
C - Steerer tube (mm)	105	120	140
D - Rear triangle (mm)	440	440	440
E - Support height (mm)	336	336	336
F - Support lowering (mm)	35	35	35
G - Wheelbase (mm)	1194	1224	1259
H - Head angle	66	66	66
I - Seat tube angle (°)	77	77	77
J - Crossover (mm)	736	766	776
K - Reach (mm)	450	474	500
L - Stack (mm)	613	627	646
M - Fork (mm)	547	547	547

Product description

Advantages

Aluminium frame

When designing this bike, the focus was on selecting the right materials to ensure the highest quality. Therefore, the frame is made of aluminium, which combines durability and low weight.

Hydraulic disc brakes

This mountain bike model uses hydraulic disc brakes, which have a very low failure rate, so they will be trouble-free even during frequent use. The undoubted advantage is greater braking power and modulation.

Full shock absorption

Allows easier traversing of off-road obstacles. Front and rear shock absorbers provide maximum wheel traction control and a balanced ride on the ground. The full suspension bike is very comfortable and soft to ride.

Drive 1x12

This bike uses 1x12 derailleurs, which provide smooth gradation and allow effortless gear changes. The large range of gear ratios allows you to adapt the gear to your current needs.

29" wheels

The use of 29 wheels has made it possible to provide more and better tyre contact with the ground, which makes it much easier to overcome bumps when riding over difficult terrain. This size guarantees good stability when riding at higher speeds.
