Fuji Nevada 29 1.3 satin silver mountain bike (11212163817-C)

Frame

Frame Fuji A2-SL custom-butted alloy front triangle, Fuji A1-SL alloy rear triangle

Frame material Aluminium

Components

Steering wheel Fuji flat bar, alloy, 710mm

Handlebar material Aluminium

Handlebar support Fuji, forged aluminum, +/-6°

Handlebar stem material Aluminium

Grips Fuji Performance Grip Lock On

Depreciation Front

Fork SR Suntour SF20-XCM-RL-DS-29, remote lockout, 100mm

Saddle WTB Volt Sport

Bar Fuji, alloy, 30.9mm

Drive

Type of derailleur Mechanical

Derailleurs 1x11

Number of gears 11

Rear derailleur (model) Shimano Deore

Handles Shimano Deore, 1 x 11-speed

Suport FSA Mega Exo, threaded

Crank mechanism FSA Gamma Pro, 30T

Cassette / Freewheel Sunrace, 11-50T

Chain KMC X11

Brakes

Brakes (model) Shimano MT200

Brake type Hydraulic discs

Brake discs 180/160 mm

Wheels

Wheel size 29"

Wheels WTB SX19 rims 32H

Tyres WTB Ranger Comp, 29" x 2.25", 27tpi

Hubs Shimano HB-TX505 front, FH-TX505 rear hub

spokes Steel

Additional information

Weight of bike (estimated) 14,36 kg

Folding condition of the bike Bike adjusted and pre-assembled

Warnings and producer's data

Producer 73557 Mutlangen, Niemcy | [email protected]

Other data

Sport Bicycles

Brand Fuji

Leading colour Silver

Season Year-round

Model/product code Nevada 29 1.3 11212163817-C

Gender Male, Woman

Country of origin of the brand Japan

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.

Code 2000063901

Size	17"	19"	21"	23"
Height (cm)	168-178	175-183	180-188	185-196
A - Seat tube (mm)	420	470	520	560
C - Rura pozioma (mm)	611	636	653	672
D - Steering tube (mm)	105	110	120	130
E - Kąt siodełka (°)	73	73	73	73
G - Kąt główki (°)	69	69	69	69
H - Rear triangle (mm)	450	450	450	450
I - Rozstaw osi (mm)	1134	1160	1177,5	1197
	55	55	55	55
K - Widelec (mm)	46	46	46	46
M - Stack (mm)	621	625,5	635	644
N - Reach (mm)	421	445	459	475
O - Cross-section (mm)	809	834,5	862	886

Advantages

Front cushioning

The cushioning on the bike provides comfort when negotiating bumps in the road. This model features front wheel cushioning, which absorbs the force when hitting an obstacle and increases the level of safety.

Aluminium frame

The aluminium frame is characterised by its high resistance to scratches and damage. In addition, this material is characterised by its low weight, which makes carrying the bike no problem.

Hydraulic disc brakes

This mountain bike is equipped with hydraulic disc brakes, which have a very low failure rate so that use will be trouble-free, even during frequent use. In addition, they feature greater braking power and modulation.

Drive 1x11

The 1x11 derailleurs used on this mountain bike allow effortless shifting and provide smooth gradation. The large gear range allows you to adjust the gearing to suit the current conditions on the trail.

29" wheels

The use of 29 wheels has made it possible to provide more and better tyre contact with the ground, which makes it much easier to overcome bumps when riding over rough terrain. This size guarantees good stability when riding at higher speeds.
