Orbea Terra M20i Team gravel bike green M11309AI (M11305AI)

Frame

Frame Orbea Terra carbon OMR Disc, monocoque construction, HS 1.5", PF30, powermeter compatible

Frame material Carbon fibre

Components

Steering wheel OC GR30 Gravel, Reach 80, Drop 125, Flare 12, w/Di2 hole

Handlebar support OC RP10 Road Performance ICR, -8º, IFC02 Computer mount interface

Depreciation No

Rudders FSA 1-1/2" Integrated Aluminium Cup

Fork Orbea Terra OMR carbon disc fork, full carbon steerer

Fork material Carbon fibre

Saddle Prologo Akero AGX STN size 155mm

Bar OC XP10 Performance Carbon SB0, 27,2mm, w/Micro tilt adjustment

Drive

Type of derailleur Electronic

Derailleurs 2x11

Number of gears 22

Front derailleur (model) Shimano FD-RX815

Rear derailleur (model) Shimano FD-RX815

Handles Shimano ST-RX815

Crank mechanism Shimano GRX RX810 31x48t

Cassette / Freewheel Shimano Ultegra HG800 11-34t 11-Speed

Chain Shimano HG 601

Brakes

Brakes (model) Shimano BR-RX810 Hydraulic disc

Brake type Hydraulic discs

Wheels

Wheel size 28"

Wheels FULCRUM Rapid Red 900 DB

Tyres Pirelli Cinturato™ Gravel H 700x40c TLR

Axle type 142 x 12 mm, 100 x 12 mm

Tubeless ready wheels Yes

Tubeless ready tyres Yes

Additional information

Lighting No

Mudguards No

Luggage carrier No

Folding condition of the bike Bike adjusted and pre-assembled

Other data

Sport Bicycles

Brand Orbea

Leading colour Green

Season Year-round

Model/product code Terra M20i Team M11309AI

Purpose Gravel

Gender Male, Woman

Country of origin of the brand Spain

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.

Code 2000055908

Size	S	M	L	XL
Height (cm)	167-172	173-179	180-185	186-191
A - Seat tube (mm)	438	471	504	537
B - Horizontal pipe (mm)	539	558	570	590
C - Steerer tube (mm)	131	152	178	199
D - Rear triangle (mm)	420	420	420	420
E - Support height (mm)	263/278	263/278	265/280	265/280
F - Support lowering (mm)	78	78	76	76
G - Wheelbase (mm)	1019	1029	1044	1053
H - Head angle	70,5	71	71	71,5
I - Seat tube angle (°)	74	73,5	73,5	73
J - Crossover (mm)	746/755	768/783	798/813	825/840
K - Reach (mm)	382	389	395	402
L - Stack (mm)	548	570	592	614
M - Fork (mm)	390	390	390	390

Advantages

Carbon frame

This bike has been created with well thought-out materials. Carbon was used for the frame, which stands out for its very low weight. In addition, this material has a high strength and resilience index.

Hydraulic disc brakes

This model of bike uses a reliable type of brake, the hydraulic disc. This type provides high braking power and modulation regardless of road conditions. In addition, the brakes have a low failure rate.

28" wheels

The 28-inch wheels are characterised by prolonged wear and allow faster speeds, which are far easier to maintain. Compared to smaller sizes, these wheels provide better stability at higher speeds.

Tubeless ready tyres

The tubeless ready system ensures that the tyre is puncture-proof, reduces rolling resistance and allows the use of lower pressures. In addition, it also eliminates the problem of ‘Snake Bite’, i.e. punctures in the inner tube by pinching the rim.

Carbon fork

The material used to make this fork is characterised by extreme lightness. The carbon fork is characterised by its high ability to absorb the power generated when riding over rough terrain and combines strength and low weight.
