Orbea Alma M30 grey/black mountain bike M22219L4

Parameters

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.

Model/product code Alma M30 M22219L4

Leading colour Grey

Brand Orbea

Country of origin of the brand Spain

Gender Male, Woman

Season Year-round

Handlebar stem material Aluminium

Crank mechanism Shimano MT611 32t

Wheel size 29"

Frame Orbea Alma Carbon OMR, Boost 12x148, PF BB, Internal cable routing

Derailleurs 1x12

Cassette / Freewheel Shimano CS-M7100 10-51t 12-Speed

Sport Bicycles

Rear derailleur (model) Shimano XT M8100 SGS Shadow Plus

Handles Shimano SLX M7100 I-Spec EV

Depreciation Front

Handlebar material Aluminium

Tubeless ready tyres Yes

Brakes (model) Shimano M6100 Hydraulic Disc

Chain Shimano M6100

Handlebar support OC1 31.8mm interface -7º

Bar OC2 forge head 27.2 Offset 0

Tyres Maxxis Rekon Race 2.35" 120 TPI Exo TLR

Frame material Carbon

Fork RockShox SID SL RL remote Q15X110 Boost DebonAir 100mm

Saddle Selle Italia Model X FecAlloy Rail 145x248mm

Steering wheel OC1 Flat 31.8mm 740mm

Brake type Hydraulic discs

Number of gears 12

Wheels Orbea OC1 25c

Stan złożenia roweru Bike adjusted and pre-assembled

Tubeless ready wheels Yes

Rudders FSA 1-1/8 - 1-1/2" Integrated

Orbea Alma M30 grey/black mountain bike M22219L4 2

Orbea Alma M30 grey/black mountain bike M22219L4

Sizes

Size	S	M	L	XL
Height (cm)	155-170	165-180	178-190	185-198
A - Seat tube (mm)	400	445	483	533
B - Horizontal pipe (mm)	559	593	618	647
C - Steerer tube (deg)	90	100	110	125
D - Rear triangle (mm)	430	430	430	430
E - Support height (mm)	309	309	309	309
F - Support lowering (mm)	61	61	61	61
G - Wheelbase (mm)	1083	1118	1144	1175
H - Head angle	68	68	68	68
I - Saddle angle	74,5	74,5	74,5	74,5
J - Crossover (mm)	693	729	749	819
K - Reach (mm)	395	426	448	474
L - Stack (mm)	593	602	612	625
M - Fork (mm)	500,8	500,8	500,8	500,8

Product description

Advantages

Carbon frame

Thanks to its flexibility, the carbon frame is characterised by its ability to absorb vibrations when riding over rough terrain. In addition, this material is characterised by its low weight, which makes carrying the bike no problem.

Hydraulic disc brakes

This mountain bike is equipped with hydraulic disc brakes, which have a very low failure rate so that use will be trouble-free, even during frequent use. In addition, they feature greater braking power and modulation.

Drive 1x12

The 1x12 derailleurs used on this mountain bike allow effortless shifting and provide smooth gradation. The large gear range allows you to adjust the gearing to suit the current conditions on the trail.

29" wheels

The use of 29 wheels has made it possible to provide more and better tyre contact with the ground, which makes it much easier to overcome bumps when riding over rough terrain. This size guarantees good stability when riding at higher speeds."
