Frame
Frame Alu 6061 T6, Sport eMTB Geometry, Smooth Welding, Bosch system Powertube 625Wh battery ready, Inner Cable Routing
Frame material Aluminium
Components
Steering wheel ONE1 Alloy, MTB AL-325BT, 6° upsweep, 9° backsweep, 25mm rise, 720mm, 31.8mm
Handlebar support ONE1 Sport MAS-D61248 Alloy, 31.8mm, -8°
Depreciation Front
Rudders ACROS AZX-254, ZS44/28.6 | EC49/30, BlockLock 150°
Fork RST Blaze, 1-1/8", 100mm travel
Saddle Selle Royal Vivo DRN
Bar ONE1 Sport Alloy, SP C207, 30.9mm
Drive
Derailleurs 1x9
Number of gears 9
Rear derailleur (model) SHIMANO ALIVIO RD-M3100 Shadow
Handles SHIMANO ALIVIO SL-M3100-R RapidFire Plus, 9-speed
Crank mechanism ONE1 EC33-BH3-F9-BNI-L/R, 38T
Cassette / Freewheel SHIMANO CS-HG200-9, 11-36T
Chain KMC e9S
Brakes
Brakes (model) SHIMANO BL-MT200/BR-MT200
Brake type Hydraulic discs
Brake discs SHIMANO SM-RT10 180 mm
Wheels
Wheel size 29"
Wheels Stars J30D, 32H
Tyres Schwalbe Hurricane Performance, 29x2.25", ADDIX
Hubs SHIMANO HB-TX505, 32H, CENTER LOCK, QR Type, SHIMANO FH-TX505-8, 32H, CENTER LOCK, M10x135mm, QR Type
Additional information
Pedals included Yes
Folding condition of the bike Bike adjusted and pre-assembled
Other data
Sport Bicycles
Brand Superior
Leading colour Red
Season Year-round
Model/product code eXC 7019 B 801.2023.79039
Purpose MTB
Gender Male, Woman
Country of origin of the brand European Union
Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only., The maximum range of an e-bike is a conventional value, depending on factors such as weather, terrain and the weight of the user.
Code 2000101068
Engine model BOSCH ActiveLine Plus
Engine location Central
Engine power 250 W
Maximum torque 50 Nm
Battery capacity 500 Wh
Charger Bosch Compact Charger
Below you will find information that will help you choose the right size when buying an eXC 7019 B electric bicycle from Superior.
| Size | 17,5" (M) | 19" (L) | 21" (XL) |
| Height (cm) | 170-180 | 181-190 | 191-200 |
| A - Seat tube (mm) | 431 | 482 | 533 |
| B - Horizontal pipe (mm) | 590 | 610 | 630 |
| C - Kąt siodełka (°) | 73,5 | 73,5 | 73,5 |
| D - Head angle (°) | 68 | 68 | 68 |
| D - Head angle (°) | 68 | 68 | 68 |
| RC | 500 | 500 | 500 |
| G - Rura sterowa (mm) |
130 | 130 | 130 |
| R - Reach (mm) | 401 | 422 | 441 |
| S - Stack (mm) | 636 | 636 | 636 |
| BBD - Support lowering (mm) | 60 | 60 | 60 |
Advantages
Front cushioning
The cushioning makes cycling over uneven ground much more pleasant and comfortable. This model is equipped with front suspension, which ensures safety and absorbs the force when the front wheel hits an obstacle.
Aluminium frame
The use of an aluminium frame in this model of bicycle makes it extremely light and strong, so that moving the bicycle from place to place is not a problem. In addition, this material is characterised by its resistance to deformation.
Hydraulic disc brakes
The given model of the bike is equipped with hydraulic disc brakes. This type has a very low failure rate, ensuring that the brakes will be trouble-free, even during frequent use. In addition, they feature greater braking power and modulation.
29" wheels
The use of 29’ wheels allows for greater and better tyre contact with the ground, making it much easier to overcome bumps when riding over rough terrain. This size guarantees good stability when riding at higher speeds.
