    Orbea Rise M10 electric bike white
    Orbea Rise M10 electric bike white 2
    Orbea Rise M10 electric bike white 3
    Orbea Rise M10 electric bike white 4
    Orbea Rise M10 electric bike white 5
    Orbea Rise M10 electric bike white 6
    Orbea Rise M10 electric bike white 7
    Orbea Rise M10 electric bike white 8
    Orbea Rise M10 electric bike white 9
    Orbea Rise M10 electric bike white 10
    Orbea Rise M10 electric bike white 11
    Orbea Rise M10 electric bike white 12
    Orbea Rise M10 electric bike white 13
    Orbea Rise M10 electric bike white 15
    Play video
    Show more (+10)
    Orbea Rise M10 electric bike white
    Orbea Rise M10 electric bike white 2
    Orbea Rise M10 electric bike white 3
    Orbea Rise M10 electric bike white 4
    Orbea Rise M10 electric bike white 5
    Orbea Rise M10 electric bike white 6
    Orbea Rise M10 electric bike white 7
    Orbea Rise M10 electric bike white 8
    Orbea Rise M10 electric bike white 9
    Orbea Rise M10 electric bike white 10
    Orbea Rise M10 electric bike white 11
    Orbea Rise M10 electric bike white 12
    Orbea Rise M10 electric bike white 13
    Orbea Rise M10 electric bike white 15

    The electric bike Orbea Rise M10 is equipped with electric assistance with a power of 250 W and a maximum torque of up to 60 Nm.

    Parameters

    Basic data

    Brand Orbea
    Country of origin of the brand Spain
    Sport Bicycles
    Gender Male, Woman
    Season Year-round
    Leading colour White
    Model/product code Rise M10 M36118YV
    Purpose MTB
    Code 2000031670

    Frame

    Frame Orbea Rise OMR 2021 Skok 140 mm 29" C-Boost 12x148
    Frame material Aluminium

    Components

    Steering wheel Race Face Next R 35 20mm Rise 780mm
    Handlebar support Race Face Aeffect R 35mm interface
    Depreciation Full
    Rudders Acros Alloy 1-1/8 - 1-1/2" Integrated
    Fork Fox 36 Float Factory 150 Grip2 QR15x110 Kashima
    Saddle Fizik Taiga S-alloy rail
    Bar OC MC20 Mountain Control Dropper, 31,6mm

    Drive

    Derailleurs 1x12
    Number of gears 12
    Rear derailleur (model) Shimano XT M8100 SGS Shadow Plus
    Handles Shimano XT M8100 I-Spec EV
    Crank mechanism E*Thirteen Plus Alu
    Cassette / Freewheel Shimano CS-M7100 10-51t 12-Speed
    Chain Shimano M7100

    Brakes

    Brakes (model) Shimano XT M8120 Hydraulic Disc
    Brake type Hydraulic discs

    Wheels

    Wheel size 29"
    Wheels Race Face TURBINE-R30 TLR 15/110mm IS
    Tyres TYRES Maxxis Dissector 2.40" 60 TPI 3CMaxxTerra Exo TLR, Maxxis Rekon 2.40" 120 TPI 3CMaxxTerra Exo+ TLR
    Tubeless ready wheels Yes
    Tubeless ready tyres Yes

    Engine

    Engine model Shimano EP8-RS
    Engine location Central
    Engine power 250 W
    Maximum torque 60 Nm

    Battery

    Battery type Lithium-ion
    Battery capacity 360 Wh
    Battery location In the frame
    Charger Orbea RS Charger (36V-2A)

    Additional information

    Lighting No
    Mudguards No
    Luggage carrier No

    Warnings and producer's data

    Standards, certificates CE
    Warnings The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only., The maximum range of an e-bike is a conventional value, depending on factors such as weather, terrain and the weight of the user.
    Producer Orbea S. Coop. | Polígono Industrial Goitondo, s/n, 48260 Mallabia, Bizkaia, Hiszpania | info@orbea.com
    Product description

    Orbea Rise M10 electric bike white (M36118YV)

    Orbea Rise M10 electric bike exceeds expectations and sets a new standard in MTB. The RS motor, battery, and electronics are more than half the weight of other eBike systems. Equipped with 250 W electric assistance and a maximum torque of up to 60 Nm.

    The Rise concept ensures efficient riding on trails, as the lighter bike, lower energy consumption, and pedal-friendly weight and assistance extend battery life by over 1.5x.

    The main part of the electric drive is the Shimano EP8 motor, making every climb effortless. The bike is equipped with a front suspension Fox 36 Float Factory 150 Grip2 QR15x110 and a rear Fox DPX2 Factory 3-Position Adjust Evol. Meanwhile, the disc brakes are the renowned Shimano models.

    The frame is made of carbon, which directly translates to a low bike weight and appropriate stiffness. The geometry allows for aggressive and dynamic riding even in challenging terrain conditions.

    Orbea Rise M10 electric bike white
    Feedback
    Feedback

    There are no reviews yet, be the first!

    Review this product

    Orbea Rise M10 electric bike white

    Orbea Rise M10 electric bike white

    Overall rating
    Please enter the order number under which you purchased this product at Sportano.

    Orbea Rise M10 electric bike white

    No opinion

    Bike assembly service available

    Size Sizes table
    Choose an Option...

    Choose an Option

    Sizes table

      Size S M L XL
      Height (cm) 150-165 160-175 170-185 180-198
      A - Seat tube (mm) 381 419 457 508
      B - Horizontal pipe (mm) 565 592 619 649
      C - Steerer tube (mm) 95 105 120 140
      D - Rear triangle (mm) 445 445 445 445
      E - Support height (mm) 336 336 336 336
      F - Support lowering (mm) 35/32 35/32 35/32 35/32
      G - Wheelbase (mm) 1180 1205 1229 1255
      H - Head angle 66/65,5 66/65,5 66/65,5 66/65,5
      I - Seat tube angle (°) 77/76,5 77/76,5 77/76,5 77/76,5
      J - Crossover (mm) 710 736 766 776
      K - Reach (mm) 425 450 474 500
      L - Stack (mm) 604 613 627 646
      M - Fork (mm) 547 547 547 547
      You save €3,870.00 €9,529.00
      €5,659.00
