Frame
Frame Orbea Kemen Mid Bar, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing, Boost 148x12
Frame material Aluminium
Components
Grips OC Lock On
Depreciation Front
Rudders FSA 1-1/2" Integrated Aluminium Cup
Fork Marzocchi Bomber Z2 100 QR15x110 E-Bike Optimised
Saddle Selle Royal Vivo Sport 160x249mm
Bar Alloy 31.6x300mm offset 0
Drive
Type of derailleur Mechanical
Derailleurs 1x10
Number of gears 10
Rear derailleur (model) Shimano Cues U6000 GS Shadow
Handles Shimano Cues SL-U6000
Crank mechanism Shimano Steps EM600
Cassette / Freewheel Shimano CS-LG300 11-48T 10-Speed
Chain KMC eGlide
Brakes
Brakes (model) Magura AT2 Hydraulic Disc Easy Route Connection
Brake type Hydraulic discs
Wheels
Wheel size 29"
Wheels Alloy, Tubeless, 29", 29c, 32H
Tyres Schwalbe Johnny Watts, 29x2.35 RaceGuard Reflective Tape
Additional information
Support Yes
Lighting Yes
Mudguards Yes
Luggage carrier Yes
Pedals included Yes
Folding condition of the bike Bike adjusted and pre-assembled
Other data
Sport Bicycles
Brand Orbea
Leading colour Black
Season Year-round
Model/product code Kemen Mid SUV 30 R33618VG
Purpose City/urban, Trekking
Gender Male, Woman
Country of origin of the brand Spain
Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only., The maximum range of an e-bike is a conventional value, depending on factors such as weather, terrain and the weight of the user.
Code 2000103893
Engine model Shimano EP801
Engine location Central
Engine power 250 W
Maximum torque 85 Nm
Battery capacity 540 Wh
Charger Orbea 2.Generation eBike Smart charger 42V/2-4A
| Size | S | M | L | XL |
| Height (cm) | 155-170 | 165-180 | 175-190 | 185-200 |
| A - Seat tube (mm) | 400 | 453 | 483 | 533 |
| B - Horizontal pipe (mm) | 563 | 576 | 606 | 642 |
| C - Steerer tube (mm) | 110 | 115 | 132 | 153 |
| D - Rear triangle (mm) | 445 | 445 | 445 | 445 |
| E - Support height (mm) | 307,5 | 307,5 | 307,5 | 307,5 |
| F - Support lowering (mm) | 63 | 63 | 63 | 63 |
| G - Wheelbase (mm) | 1134 | 1142 | 1173 | 1211 |
| H - Head angle | 66,5 | 67 | 67 | 67 |
| I - Seat tube angle (°) | 75 | 75 | 75 | 75 |
| J - Crossover (mm) | 781 | 810 | 833 | 866 |
| K - Reach (mm) | 405 | 415 | 440 | 470 |
| L - Stack (mm) | 617 | 624 | 640 | 659 |
| M - Fork (mm) | 513,5 | 513,5 | 513,5 | 513,5 |
| Rake | 44 | 44 | 44 | 44 |
Advantages
Front cushioning
The cushioning makes cycling over uneven ground much more pleasant and comfortable. This model is equipped with front suspension, which ensures safety and absorbs the force when the front wheel hits an obstacle.
Aluminium frame
The use of an aluminium frame in this model of bicycle makes it extremely light and strong, so that moving the bicycle from place to place is not a problem. In addition, this material is characterised by its resistance to deformation.
Hydraulic disc brakes
The given model of the bike is equipped with hydraulic disc brakes. This type has a very low failure rate, ensuring that the brakes will be trouble-free, even during frequent use. In addition, they feature greater braking power and modulation.
Drive 1x10
The 1x10 derailleurs used on this e-bike model guarantee smooth gradation and allow effortless gear changes. The large gear range allows you to adapt the gear to the current road conditions.
29" wheels
The use of 29’ wheels allows for greater and better tyre contact with the ground, making it much easier to overcome bumps when riding over rough terrain. This size guarantees good stability when riding at higher speeds.
