Orbea Oiz M11 AXS orange/black mountain bike M23719LE (M23719LE)

Frame

Frame Orbea Oiz Carbon OMR AlloyLink Boost PF Taper UFO2 I-Line

Frame material Carbon fibre

Components

Steering wheel OC MP10 Mountain Performance Carbon, Width 760, Sweep 9

Handlebar width 760 mm

Handlebar support OC MP20 Mountain Performance, -8º

Depreciation Full

Rudders Acros Alloy 1-1/8 - 1-1/2" Integrated

Fork Fox 34 Float SC Performance 100 FIT4 3POS Remote Push-Unlock QR15x110

Damper Fox i-line DPS Performance 100mm Remote Push-Unlock Evol custom tune190x40mm

Saddle Fizik Taiga S-alloy rail Consult other components

Bar OC2 forge head 31.6 Offset 0

Drive

Derailleurs 1x12

Number of gears 12

Rear derailleur (model) SRAM GX1 Eagle AXS Lunar

Handles SRAM GX Eagle AXS

Crank mechanism SRAM GX Eagle Dub Lunar Boost 32t

Cassette / Freewheel SRAM XG-1275 Eagle 10-52t 12-Speed

Chain SRAM GX Eagle 12-Speed

Brakes

Brakes (model) Shimano M6100 Hydraulic Disc

Brake type Hydraulic discs

Wheels

Wheel size 29"

Wheels DT Swiss X-1900 Spline 25c TLR 15/110mm CL

Tyres Maxxis Rekon Race 2.35" 120 TPI Exo TLR

Tubeless ready wheels Yes

Tubeless ready tyres Yes

Additional information

Lighting No

Mudguards No

Luggage carrier No

Folding condition of the bike Bike adjusted and pre-assembled

Other data

Sport Bicycles

Brand Orbea

Leading colour Orange

Season Year-round

Model/product code Oiz M11 AXS M23719LE

Purpose MTB

Gender Male

Country of origin of the brand Spain

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only.

Size	S	M	L	XL
Height (cm)	155-165	165-180	178-190	185-198
A - Seat tube (mm)	405	432	470	520
B - Horizontal pipe (mm)	564	593	617	641
C - Steerer tube (mm)	90	95	105	120
D - Rear triangle (mm)	435	435	435	435
E - Support height (mm)	327	327	327	327
F - Support lowering (mm)	47	47	47	47
G - Wheelbase (mm)	1094	1123	1148	1173
H - Head angle	69	69	69	69
I - Seat tube angle (°)	75	75	75	75
J - Crossover (mm)	717	732	742	749
K - Reach (mm)	407	435	456	476
L - Stack (mm)	586	591	600	614
M - Fork (mm)	504	504	504	504

Advantages

Carbon frame

When designing this bike, the focus was on selecting the right materials to ensure the highest quality. Therefore, the frame is made of carbon, which combines lightness and resilience in addition to effectively damping vibrations.

Hydraulic disc brakes

This mountain bike model uses hydraulic disc brakes, which have a very low failure rate, so they will be trouble-free even during frequent use. The undoubted advantage is greater braking power and modulation.

Tubeless ready tyres

The use of TLR (Tubeless Ready) technology has made it possible to use lower pressures and makes the tyres resistant to punctures. What's more, the system rules out the problem of ‘Snake Bite’, i.e. puncturing the inner tube by pinching it against the rim.

Full shock absorption

Allows easier traversing of off-road obstacles. Front and rear shock absorbers provide maximum wheel traction control and a balanced ride on the ground. The full suspension bike is very comfortable and soft to ride.

Drive 1x12

This bike uses 1x12 derailleurs, which provide smooth gradation and allow effortless gear changes. The large range of gear ratios allows you to adapt the gear to your current needs.

29" wheels

The use of 29 wheels has made it possible to provide more and better tyre contact with the ground, which makes it much easier to overcome bumps when riding over difficult terrain. This size guarantees good stability when riding at higher speeds.
