The electric bike Orbea Kemen Mid SUV 30 is perfect for urban conditions. Modern technologies provide comfort and safety on every road. With a powerful motor and durable construction, daily rides are pure pleasure.

Basic data

Brand Orbea
Country of origin of the brand Spain
Sport Bicycles
Gender Male, Woman
Season Year-round
Leading colour Orange
Model/product code Kemen Mid SUV 30 R33618VF
Purpose City/urban, Trekking
Code 2000103892

Frame

Frame Orbea Kemen Mid Bar, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing, Boost 148x12
Frame material Aluminium

Components

Grips OC Lock On
Depreciation Front
Rudders FSA 1-1/2" Integrated Aluminium Cup
Fork Marzocchi Bomber Z2 100 QR15x110 E-Bike Optimised
Saddle Selle Royal Vivo Sport 160x249mm
Bar Alloy 31.6x300mm offset 0

Drive

Type of derailleur Mechanical
Derailleurs 1x10
Number of gears 10
Rear derailleur (model) Shimano Cues U6000 GS Shadow
Handles Shimano Cues SL-U6000
Crank mechanism Shimano Steps EM600
Cassette / Freewheel Shimano CS-LG300 11-48T 10-Speed
Chain KMC eGlide

Brakes

Brakes (model) Magura AT2 Hydraulic Disc Easy Route Connection
Brake type Hydraulic discs

Wheels

Wheel size 29"
Wheels Alloy, Tubeless, 29", 29c, 32H
Tyres Schwalbe Johnny Watts, 29x2.35 RaceGuard Reflective Tape

Engine

Engine model Shimano EP801
Engine location Central
Engine power 250 W
Maximum torque 85 Nm

Battery

Battery capacity 540 Wh
Charger Orbea 2.Generation eBike Smart charger 42V/2-4A

Additional information

Support Yes
Lighting Yes
Mudguards Yes
Luggage carrier Yes
Pedals included Yes

Warnings and producer's data

Standards, certificates CE
Warnings The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only., The maximum range of an e-bike is a conventional value, depending on factors such as weather, terrain and the weight of the user.
Producer Orbea S. Coop. | Polígono Industrial Goitondo, s/n, 48260 Mallabia, Bizkaia, Hiszpania | info@orbea.com

Orbea Kemen Mid SUV 30 540Wh 2024 mango/black electric bike (R33618VF)

Orbea Kemen Mid SUV 30 540Wh 2024 is a sophisticated combination of modern technology and practical solutions, perfectly meeting the needs of the contemporary urban user. This e-bike stands out not only for its high performance and reliability but also for its elegant aesthetics and exceptional comfort, making it an excellent choice for demanding cyclists moving in urban and suburban environments.

The heart of the bike is a frame made of hydroformed 6061 series aluminum, characterized by exceptional lightness and resistance to deformation. Advanced hydroforming technology allows the creation of complex shapes without compromising strength, which translates into better aerodynamics and increased stiffness of the entire structure.

Integration of the Shimano Steps system with the battery and internal cable routing not only enhances aesthetics but also effectively protects sensitive electrical components from harmful external factors. The use of the Boost 148x12 standard further strengthens the construction, ensuring unparalleled stability during riding.

The Shimano EP801 motor with a power of 250 W and torque of 85 Nm provides powerful support, making it easier to overcome steep climbs and long distances without excessive effort. Its advanced technology ensures quiet operation and energy efficiency, which is crucial for long-term urban use. The 540 Wh battery delivers sufficient range to easily complete long routes or daily commutes without frequent charging. Fast charging is another advantage, allowing efficient time management between rides.

The Marzocchi Bomber Z2 fork, optimized for electric bikes, offers advanced suspension that effectively absorbs terrain irregularities, increasing comfort and control over the bike in challenging urban and off-road conditions.

Orbea Kemen Mid SUV 30 is equipped with practical accessories that enhance its functionality in everyday use. The kickstand allows convenient parking of the bike anywhere, mudguards protect against dirt during rides on rainy days, and the rack offers additional space for carrying shopping or luggage.

UVEX bike helmet Viva 3 black S4109840115
Size
52-57 cm
56-62 cm
Choose an Option...

Choose an Option

  • 52-57 cm €66.99 €47.99
  • 56-62 cm €66.99 €47.99
Add to Wish List
CamelBak Podium Chill bicycle bottle 710 ml black
Size
710 ml
Choose an Option...

Choose an Option

  • 710 ml €19.99 €17.99
Add to Wish List
Elite bicycle kit Custom Race Plus basket + Elite Fly Tex Maillot Jaune 550 ml bottle black
Size
550 ml
Choose an Option...

Choose an Option

  • 550 ml €23.99
Add to Wish List
Bike stand Orbea Onna/MX black
Size
27.5"-29"
Choose an Option...

Choose an Option

  • 27.5"-29" €42.99 €38.99
Add to Wish List
Feedback

There are no reviews yet, be the first!

Review this product

Orbea Kemen Mid SUV 30 540Wh 2024 mango/black electric bike

Orbea Kemen Mid SUV 30 540Wh 2024 mango/black electric bike

Overall rating
Please enter the order number under which you purchased this product at Sportano.

Orbea Kemen Mid SUV 30 540Wh 2024 mango/black electric bike

No opinion

Bike assembly service available

Size Sizes table
Choose an Option...

Choose an Option

Sizes table

    Size S M L XL
    Height (cm) 155-170 165-180 175-190 185-200
    A - Seat tube (mm) 400 453 483 533
    B - Horizontal pipe (mm) 563 576 606 642
    C - Steerer tube (mm) 110 115 132 153
    D - Rear triangle (mm) 445 445 445 445
    E - Support height (mm) 307,5 307,5 307,5 307,5
    F - Support lowering (mm) 63 63 63 63
    G - Wheelbase (mm) 1134 1142 1173 1211
    H - Head angle 66,5 67 67 67
    I - Seat tube angle (°) 75 75 75 75
    J - Crossover (mm) 781 810 833 866
    K - Reach (mm) 405 415 440 470
    L - Stack (mm) 617 624 640 659
    M - Fork (mm) 513,5 513,5 513,5 513,5
    Rake 44 44 44 44
