Frame
Frame Alu X6 Ultralite, Advanced eMTB Geometry, SHIMANO STEPS ready, Integrated battery, SR dropout, Boost 12x148 mm
Frame material Aluminium
Components
Steering wheel ONE1 Alloy, MTB AL-320BT, 10° backsweep, 20mm rise, 720mm, 31.8mm
Handlebar support ONE1 TDS-661 Alloy, 31.8mm, 0°
Depreciation Front
Rudders ACROS AZX-1051, ICR, ZS56/28.6 | ZS56/40; BlockLock 120°
Fork RockShox Judy Silver TK, Tapered, SoloAir, 15x110mm axle, 100mm travel
Saddle Selle Royal LIFT
Bar ONE1 Sport Alloy, SP C207, 30.9mm
Drive
Derailleurs 1x12
Number of gears 12
Rear derailleur (model) SHIMANO DEORE RD-M6100 Shadow Plus
Handles SHIMANO DEORE SL-M6100-IR RapidFire Plus, 12-speed
Crank mechanism SHIMANO FC-E6000, 34T
Cassette / Freewheel SHIMANO CS-M6100-12, 10-51T
Chain SHIMANO CN-M6100
Brakes
Brakes (model) SHIMANO BL-M4100/BR-MT420
Brake type Hydraulic discs
Wheels
Wheel size 29"
Wheels Stars J30D, 32H
Tyres Schwalbe G-One Allround Performance, 29x2.25", ADDIX
Hubs SHIMANO HB-MT410-B, 32H, CENTER LOCK, 15x110mm THRU Type AXLE, SHIMANO FH-MT410, 32H, CENTER LOCK, 12x148mm THRU Type AXLE
Additional information
Pedals included Yes
Folding condition of the bike Bike adjusted and pre-assembled
Other data
Sport Bicycles
Brand Superior
Leading colour Green
Season Year-round
Model/product code eXR 6090 L Touring 801.2022.78004
Purpose Cross/Fitness
Gender Male, Woman
Country of origin of the brand European Union
Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only., The maximum range of an e-bike is a conventional value, depending on factors such as weather, terrain and the weight of the user.
Code 2000089652
Engine model SHIMANO STEPS EP800
Engine location Central
Engine power 250 W
Maximum torque 85 Nm
Battery capacity 504 Wh
Charger DARFON 4A Smart Plus charger
Below you will find information that will help you choose the right size when buying an eXR 6090 L Touring electric bicycle from Superior.
| Size | S/16,5" |
| Height (cm) | 160-175 |
| A - Seat tube (mm) | 420 |
| B - Horizontal pipe (mm) | 580 |
| C - Kąt siodełka (°) | 73,5 |
| D - Head angle (°) | 68 |
| F - Wheel base (mm) | 1117 |
| G - Rura sterowa (mm) |
120 |
| R - Reach (mm) | 401 |
| S - Stack (mm) | 604 |
| BBD - Support lowering (mm) | 60 |
Advantages
Front cushioning
The cushioning makes cycling over uneven ground much more pleasant and comfortable. This model is equipped with front suspension, which ensures safety and absorbs the force when the front wheel hits an obstacle.
Aluminium frame
The use of an aluminium frame in this model of bicycle makes it extremely light and strong, so that moving the bicycle from place to place is not a problem. In addition, this material is characterised by its resistance to deformation.
Hydraulic disc brakes
The given model of the bike is equipped with hydraulic disc brakes. This type has a very low failure rate, ensuring that the brakes will be trouble-free, even during frequent use. In addition, they feature greater braking power and modulation.
Drive 1x12
The 1x12 derailleurs used on this e-bike model guarantee smooth gradation and allow effortless gear changes. The large gear range allows you to adapt the gear to the current road conditions.
29" wheels
The use of 29’ wheels allows for greater and better tyre contact with the ground, making it much easier to overcome bumps when riding over rough terrain. This size guarantees good stability when riding at higher speeds.
