EcoBike SX4/LG electric bike 17.5 Ah red 1010402(2023) (1010402(2023))

Components

Steering wheel Zoom MTB-AL-312BT (22,2 mm x 31,8 mm x 720 mm)

Handlebar support Promax MA-47 (31,8 mm x 90 mm)

Fork SunTour XCM HLO DS 27,5, 100 mm

Saddle Velo VL-3363 NP1

Bar PROMAX SP－252 (27,2 mm x 350 mm)

Drive

Derailleurs 3x9

Number of gears 27

Front derailleur (model) Microshift Marvo

Rear derailleur (model) Microshift Marvo

Handles Microshift Marvo Xpress Shifters 3x9

Crank mechanism Shimano AFCM371C422CL 170 mm / 44x32x22T

Cassette / Freewheel SUNRACE MFE90 9CU / 13-32T / 9 SPEED

Chain KMC X9

Brakes

Brakes (model) ALHONGA HJ-HT472

Brake type Hydraulic discs

Wheels

Wheel size 27,5"

Wheels Three-chambered rim

Tyres TRC Dryjack 27.5 "x2.1

Additional information

Lighting No

Mudguards No

Luggage carrier No

Weight of bike (estimated) 25,3 kg

Folding condition of the bike Bike adjusted and pre-assembled

Other data

Sport Bicycles

Brand EcoBike

Leading colour Red

Season Year-round

Model/product code SX4/LG 17.5 Ah el. 1010402(2023)

Purpose MTB

Gender Male, Woman

Country of origin of the brand Poland

Reservations The manufacturer reserves the right to change specifications, materials and equipment, so please refer to the current technical description on the product sheet below. The photos are for illustrative purposes only., The maximum range of an e-bike is a conventional value, depending on factors such as weather, terrain and the weight of the user.

Model colour 2000059623

Engine model Bafang

Engine location Hub

Engine power 250 W

Maximum engine power 560 W

Maximum torque 45 Nm

Battery type Lithium-ion

Battery capacity 630 Wh

Battery location In the frame

Maximum range 140 km

Charger 220-240V／42V / 2A / D type

Frame size	19"
Height (cm)	165-180
A - Rura pozioma (mm)	595
B - Rura sterowa (mm)	160
C - Rura podsiodłowa (mm)	482
D - Wheel base (mm)	1095,8
E - Kąt siodełka (°)	73
F - Kąt główki (°)	70

Advantages

Front cushioning

The cushioning makes cycling over uneven ground much more pleasant and comfortable. This model is equipped with front suspension, which ensures safety and absorbs the force when the front wheel hits an obstacle.

Aluminium frame

The use of an aluminium frame in this model of bicycle makes it extremely light and strong, so that moving the bicycle from place to place is not a problem. In addition, this material is characterised by its resistance to deformation.

Hydraulic disc brakes

The given model of the bike is equipped with hydraulic disc brakes. This type has a very low failure rate, ensuring that the brakes will be trouble-free, even during frequent use. In addition, they feature greater braking power and modulation.

29" wheels

The use of 29’ wheels allows for greater and better tyre contact with the ground, making it much easier to overcome bumps when riding over rough terrain. This size guarantees good stability when riding at higher speeds.
